Al Shakru Sheets and Plates, a highly respected manufacturer and supplier located in Dubai, UAE, is recognized for its premium stainless steel products, including the well-regarded Stainless Steel 321 Angles. Known for precision engineering and exceptional durability, Al Shakru Sheets and Plates provides angles that stand out in corrosion resistance, high-temperature stability, and enduring structural performance. Engineered to satisfy demanding industrial standards, these Stainless Steel 321 Angles are ideal for applications requiring both dependability and thermal resistance. Whether used in industrial, commercial, or architectural projects, these angles combine accurate dimensions with robust mechanical properties. Al Shakru Sheets and Plates remains dedicated to supplying clients with superior stainless steel solutions customized to address a wide range of engineering and construction requirements.
The Stainless Steel 321 Angle consists mainly of iron, together with 17–19% chromium, 9–13% nickel, and modest quantities of titanium, manganese, and additional alloying elements. This distinctive makeup delivers outstanding resistance to intergranular corrosion and superb oxidation resistance under high temperatures. Generally, these angles feature a tensile strength of 620–750 MPa, a yield strength of 275–310 MPa, and an elongation of 30–40%, guaranteeing that they are both long-lasting and mechanically dependable. Stainless Steel 321 Angles preserve their structural integrity and dimensional stability even under extended exposure to high temperatures, which makes them perfect for industrial, chemical, and high-temperature engineering applications.
Specifications :ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range :20 x 20 mm to 100 x 100 mm
Angles Thickness :3 to 12 mm (varies by size)
Channel Size Range :Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness :5 to 6 mm (varies by size)
Length :3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying premium products, we serve a broad range of industries, offering dependable solutions for varied applications. Our large inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Stainless steel 321 angleprovides outstanding corrosion resistance, particularly against high temperatures and acidic environments, making it well suited for use in industries such as aerospace, chemical processing and automotive It offers excellent weldability, formability and strength, guaranteeing durability and structural integrity in critical applications . The inclusion of titanium enhances the stability of the alloy, prevents carbide precipitation during welding, boosts its performance in high temperature environments This stainless steel also delivers excellent resistance to scaling and oxidation , ensures long-term reliability and minimal maintenance under extreme conditions Its versatile nature in construction engineering . of applications Makes it suitable for a wide range of applications.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
These angles see extensive use in industries demanding corrosion resistance, strength, and stability under high temperatures. Typical applications include structural frameworks, pressure vessels, heat exchangers, boiler components, and chemical processing equipment. They work well for furnace parts, exhaust systems, and a range of high-temperature industrial machinery. On top of that, these angles have a role in architectural and construction projects where durability and performance matter most.
