Al Shakru Sheets and Plates, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of Stainless Steel 310H Angles . These angles are renowned for their exceptional strength at high temperatures, corrosion resistance, and long-lasting durability. Made from a unique combination of high-chromium, high-nickel austenitic stainless steel featuring an elevated carbon content, they deliver enhanced creep resistance and mechanical stability even under intense heat. At Al Shakru Sheets and Plates, accurate manufacturing and rigorous quality control are top priorities, guaranteeing that their 310H angles comply with international standards. Ideal for industrial, chemical, and power generation applications, these angles ensure enduring performance, structural strength, and reliable operation in demanding, high-temperature, and corrosive conditions.
Stainless Steel 310H Angles consist of chromium (24–26%) and nickel (19–22%), along with a higher carbon level that enhances their strength at high temperatures and resistance to creep. They feature a tensile strength of approximately 620 MPa, a yield strength of 310 MPa, and an elongation of 35%. Having a density of 8.0 g/cm³ and a melting range of 1390–1425°C, these angles retain remarkable toughness, weldability, and mechanical stability even when exposed to high temperatures and severe conditions.
| Specifications | : | ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| SS 310H Angle | : | 5mm to 9mm |
| SS 310H Channel | : | 40mm*20mm~300mm*300mm |
| SS 310H Beam | : | 3″ thru 12.31″ |
| SS 310H Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 310H | 0.04 – 0.10 | 2 max | 1.0 max | 0.045 max | 0.030 max | 24 – 26 | – | 19 – 21 | 53.885 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310H | S31009 |
We provide items supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to satisfy our customers specific needs. With an emphasis on delivering superior products, we serve a broad range of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Stainless steel 310H angleoffers outstanding protection against high temperature oxidation and corrosion, which makes it well suited for use in furnaces, heat exchangers and exhaust systems Its elevated chromium and nickel content delivers outstanding strength and durability last longer at elevated temperatures. The alloy has outstanding weldability and formability, which makes it appropriate for structural applications. Additionally, the stainless steel 310H surface maintains its mechanical properties in zones of thermal cycling and chemical exposure These characteristics guarantee durability and reliability in applications such as petrochemical, aerospace, and in power generation.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 310H Angles are used across a wide range of applications requiring outstanding high-temperature capability and resistance to corrosion. They are especially well-suited for furnace parts, heat exchangers, boilers, chimneys, and machinery employed in chemical processing. In addition, they serve an important function in power generation, petrochemical plants, and industrial structures where thermal stability, longevity, and oxidation resistance are critical. Their remarkable behavior under intense heat and corrosive conditions makes them a perfect choice for structural, industrial, and high-performance engineering ventures.
