Al Shakru Sheets and Plates, based in Dubai, UAE, is a well-regarded manufacturer and supplier of Stainless Steel 301 Angles . These angles are known for their impressive strength, exceptional corrosion resistance, and notable ductility. Made from austenitic stainless steel with excellent work-hardening characteristics, they’re ideal for applications requiring both structural integrity and flexibility. At Al Shakru Sheets and Plates, precise manufacturing combines with strict quality control, guaranteeing that their 301 angles comply with international standards. Whether used for industrial, chemical, or architectural purposes, these angles offer durability, dependable structural support, and resistance to oxidizing and mildly corrosive conditions, making them a preferred option for demanding fabrication and engineering projects.
Stainless Steel 301 Angles consist of chromium (16–18%) and nickel (6–8%), elements that give them outstanding resistance to corrosion, mechanical strength, and ductility. They feature a tensile strength of approximately 620 MPa, a yield strength of 290 MPa, and 40% elongation. Having a density of 8.0 g/cm³ and a melting range spanning 1400–1450°C, these angles deliver superb toughness, weldability, and formability, guaranteeing dependable performance across both structural and industrial applications.
| Specifications | ASTM A276 / ASME SA276 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Angles Size | 20mm to 200mm |
| Angle Thickness | 3mm to 12mm |
| Angles Length | Upto 6 Meters Long |
| Angles Types | Equal, Unequal, L Angle, Equal Leg Angle, Unequal Leg Angle, Hot Rolled Angle, Angle |
| ELEMENT | C | Mn | P | S | Si | Cr | Ni | N |
|---|---|---|---|---|---|---|---|---|
| SS 301 | 0.150 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.10 |
| SS 301L | 0.03 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.02 |
| Grade | Tensile Strength ksi (min.) | Yield Strength 0.2% ksi (min.) | Elongation -% in 50 mm (min.) |
|---|---|---|---|
| SS 301 | 185 | 140 | 9 |
| SS 301L | 550 | 220 | 45 |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
|---|---|---|---|
| SS 301 | 1.4310 | S30100 | SUS 301 |
| SS 301L | – | S30103 | SUS 301L |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying top-tier products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Stainless steel 301 Angleprovides outstanding corrosion resistance, particularly in bright settings, which makes it well suited for outdoor marine uses. It offers consistency and can be shaped with ease. The alloy delivers high tensile strength and moderate hardness, guaranteeing durability and structural integrity. It also demonstrates excellent fatigue resistance and readily cracks under stress, making it ideal for applications in the industrial and construction industries In addition to stainless steel 301 Angle keeps its properties in environments that are extremely hot, delivering versatility and reliability.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 301 Angles are used across a range of applications that demand high strength, formability, and corrosion resistance. They work well for automotive components, chemical processing equipment, kitchen and food processing tools, industrial machinery, and structural frameworks. On top of that, they serve in pressure vessels, fabrication projects, and high-performance engineering applications where durability, mechanical stability, and resistance to oxidizing environments matter greatly. Their exceptional performance makes them well-suited for a wide range of industrial and structural applications.
