Al Shakru Sheets and Plates, based in Dubai, UAE, has established a strong reputation as a dependable manufacturer and supplier of Stainless Steel 316Ti Angles . These angles are renowned for their outstanding strength, corrosion resistance, and lasting durability. Crafted from titanium-stabilized austenitic stainless steel, they provide excellent protection against intergranular corrosion and high-temperature oxidation. Al Shakru Sheets and Plates focuses on precision-engineered 316Ti angles that are ideally suited for a wide range of applications, such as industrial, marine, and architectural projects, all while adhering to international quality standards. Owing to their advanced manufacturing techniques and strict quality control, each 316Ti angle is built to deliver outstanding performance in demanding environments, making them a preferred choice for numerous structural and fabrication requirements.
The Stainless Steel 316Ti Angle consists of chromium (16–18%), nickel (10–14%), molybdenum (2–3%), and titanium for stabilization, which markedly enhances its resistance to sensitization and scaling under high temperatures. It offers a tensile strength of roughly 515 MPa, a yield strength of 205 MPa, and an elongation of 40%. Featuring a density of about 8.0 g/cm³ and a melting point ranging from 1375–1400°C, this alloy is recognized for its outstanding formability, weldability, and toughness, retaining its mechanical stability in both cryogenic and high-temperature environments.
| Standard | ASME, ASTM, EN, BS, GB, DIN, JIS, etc |
| Size | 3/4″ THRU 8″ |
| Thickness | 1/8″ thru 5/8″ |
| Type | Stuctural Steel Angle, Bars, Equal, Unequal, L, T, Hot Rolled |
| Grades | 304/304L/304H/310S/316/316L/316H/316TI/317/317L/321/321H/904L |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| SS 316Ti | 0.08 max | 2 max | 0.75 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.395 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 316 | 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| SS 316Ti | 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| SS 316Ti | 1.4571 | S31635 | SUS 316Ti | 320S31 | 08Ch17N13M2T | Z6CNDT17‐123 | X6CrNiMoTi17-12-2 |
We supply materials accompanied by mill test certificates as well as third-party test certificates, guaranteeing top-tier standards of quality and compliance.
Al Shakru Sheets and Plates, headquartered in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our large inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
The stainless steel 316Ti angle delivers outstanding corrosion resistance owing to its titanium-tough construction particularly in high-temperature settings that preserves this strength and stability under extreme conditions, and offers it is well suited for industrial marine uses. The alloy withstands pitting and crevice corrosion, delivering durability in high chloride settings. In addition, it demonstrates superb weldability and formability, easing mass production. Its sophisticated mechanical properties and heat resistance render it appropriate for pressure molds and chemical processes, yielding dependable operation and lower maintenance over time.
| THICKNESS | ||||||
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Stainless Steel 316Ti Angles are used across industries that demand strong corrosion resistance and durability at high temperatures. You’ll often find them in chemical processing facilities, marine equipment, heat exchangers, pressure vessels, and architectural structures. On top of that, they serve an essential function in power generation, pharmaceuticals, and food processing industries thanks to their remarkable resistance to oxidation and scaling. What’s more, 316Ti angles perform exceptionally well in chloride-rich settings, which makes them a perfect fit for coastal buildings and offshore installations, where they deliver lasting durability and dependability under tough, corrosive conditions.
