Al Shakru Sheets and Plates, based in Dubai, UAE, distinguishes itself as a leading manufacturer and supplier of Stainless Steel 253MA Channels . These channels are renowned for their exceptional capacity to withstand high-temperature oxidation and corrosion. Made from a high-alloy austenitic stainless steel, they are purpose-built to handle sustained exposure to elevated temperatures, delivering an excellent blend of creep strength and mechanical performance. At Al Shakru Sheets and Plates, precise manufacturing and rigorous quality control take top priority, guaranteeing that their 253MA channels comply with international standards. Ideal for power generation, chemical processing, and a range of industrial applications, these channels deliver enduring structural integrity, dependable performance, and resistance to scaling, making them well-suited for demanding high-temperature engineering projects.
Stainless Steel 253MA Channels contain chromium (21%), nickel (11%), molybdenum (0.5%), and nitrogen, a combination that delivers outstanding high-temperature strength, resistance to oxidation, and mechanical stability. They offer a tensile strength of roughly 550 MPa, a yield strength of 230 MPa, and an elongation of 40%. Featuring a density of 7.9 g/cm³ and a melting range of 1400–1450°C, these channels retain remarkable toughness, weldability, and formability, guaranteeing dependable performance even in demanding high-temperature and corrosive conditions.
| Standard | ASTM A240 / ASME SA240, ASTM A276 / A182, ASTM A479 – AL-6XN, A286 |
| Width | 1000mm-2000mm |
| Thickness | 1.0mm – 100mm |
| Specialize | Shim Sheet, Perforated Sheet, B. Q. Profile. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Coil, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Si | Mn | P | S | Cr | Ni | N | Ce |
| 253MA | 0.05 – 1 | 1.1 – 2.0 | ≤0.8 | ≤0.040 | ≤0.030 | 20 – 22 | 10-Dec | 0.14 – 0.2 | 0.03 – 0.08 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Reduction Area,% |
|---|---|---|---|---|
| 253 MA | 87,000 | 45,000 | 40 | 50 |
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to satisfy our customers specific needs. With an emphasis on supplying superior products, we serve a broad range of industries, offering dependable solutions for varied applications. Our large inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Stainless Steel 253MA Channelprovides many benefits, especially its outstanding resistance to oxidation and scaling under high temperatures, which makes it well-suited for use in power generation, petrochemicals, and heat exchangers. Its considerable strength and creep resistance guarantee dependability in tough conditions, even when temperatures rise. The alloy additionally offers good weldability and formability, allowing it to be readily shaped into a range of forms and dimensions. Furthermore, Stainless Steel 253MA resists corrosion and shows exceptional resistance to thermal fatigue, delivering lasting durability in severe, high-temperature environments.
Yes,we offer custom sizes for Stainless Steel 253Ma Channel to fit particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
| STANDARD | UNS | WNR. |
|---|---|---|
| SS 253 MA | S30815 | 1.4835 |
Stainless Steel 253MA Channels are widely applied in situations that require high-temperature durability along with resistance to corrosion. They work exceptionally well for boiler components, heat exchangers, furnace parts, and industrial chimneys. In addition, they serve in power plants, petrochemical facilities, and offshore structures where thermal stability, structural integrity, and resistance to oxidizing conditions are crucial. Their remarkable performance under extreme conditions makes them a preferred option for fabrication, high-temperature structural, and industrial engineering projects.
