Al Shakru Sheets and Plates distinguishes itself as a leading manufacturer and supplier based in Dubai, UAE, with expertise in high-quality SA537 Class 2 Boiler Sheets and Plates . These plates are skillfully engineered for pressure vessel and heat exchanger applications, where strength and dependability cannot be compromised. At Al Shakru Sheets and Plates, precision engineering and superior quality control take center stage, guaranteeing that every product complies with ASTM standards and provides exceptional mechanical performance. Celebrated for their impressive toughness, durability, and weldability, the SA537 Class 2 plates from Al Shakru Sheets and Plates are ideally suited for industries such as petrochemical, power generation, and oil refining, particularly in settings involving high pressures and temperatures.
The SA537 Class 2 Boiler Sheets and Plates are chiefly composed of carbon, manganese, phosphorus, sulfur, and silicon. This variety of pressure vessel quality steel is heat treated via normalization and tempering, which considerably enhances its strength and toughness. It features a minimum yield strength of roughly 485 MPa and remarkable tensile strength spanning from 620 to 690 MPa. These plates are recognized for their outstanding impact resistance, steadiness at elevated temperatures, and excellent weldability, rendering them perfect for building sturdy and secure pressure vessels and boiler components in demanding environments.
Grade : ASME SA 537 CL.2 Boiler and Pressure Vessel Steel Plates
Width : 1000mm-4500mm
Thickness : 5mm-150mm
Length : 3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or according to customer specifications.
Impact tested : -52° C
Tempering : Notch toughness can be enhanced through quenched cooling following hot rolling or normalizing performed by the supplier. When such an accelerated cooling rate is mutually agreed between purchaser and supplier, the steel must additionally undergo tempering at 1200 F.
Applications : Applied in Boiler and Pressure Vessel usage.
Process of Manufacturing : Hot-Rolled (HR)
| C | Mn | P | S | Si | Cr | Cu | Ni | Mo | |
| ≤ 40 mm | > 40 mm | ||||||||
| 0.24 max | 0.70/1.35 | 1.00/1.60 | 0.035 | 0.035 | 0.15/0.50 | 0.025 | 0.35 | 0.25 | 0.080 |
| Grade | Heat Treatment | Tensile (MPa) | Yield (MPa) | Elongation |
| SA537 Class 2 | Quenched and tempered | 550–690 | 415 | 22% |
| Steel Grade | JIS | Germany |
| ASTM/ASME | G3115 | DIN17155 |
| A537 / SA537 | SPV36 | 19Mn5 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
SA537 Class 2 boiler sheet and plate deliver outstanding strength and durability, which makes them well-suited for pressure vessels and boiler applications. They undergo heat treatment to enhance their hardness, guaranteeing resistance to high-pressure conditions and elevated temperatures. The material shows excellent weldability, allowing straightforward fabrication into complex shapes. Its ability to resist corrosion and cracking under stress makes it appropriate for demanding industrial environments. Furthermore, SA537 Class 2 offers good toughness and impact resistance, securing long-term reliability in tough applications like power plants and chemical processing.
You’ll commonly see SA537 Class 2 Boiler Sheets and Plates applied in boilers, pressure vessels, heat exchangers, storage tanks, and refinery equipment . Their remarkable strength and durability make them ideal for uses that deal with high pressure and elevated temperatures. On top of that, these plates serve chemical processing plants, thermal power plants, and industrial steam systems , where enduring performance and safety are essential. Thanks to their superior mechanical properties and steady dependability, SA537 Class 2 plates ensure efficient, safe, and long-lasting performance across a wide range of vital industrial applications.
