Al Shakru Sheets and Plates, a highly regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Stainless Steel 317L Sheets and Plates . These products are renowned for their exceptional corrosion resistance, strength, and durability, particularly in demanding environments. Produced using advanced manufacturing methods and superior raw materials, these sheets and plates deliver remarkable dimensional accuracy, a fine surface finish, and enduring reliability. Al Shakru Sheets and Plates makes certain that their products comply with international standards, rendering their Stainless Steel 317L Sheets and Plates ideal for a range of industrial, chemical, and marine uses. Thanks to their outstanding performance under pressure and resistance to pitting and crevice corrosion, they have earned the confidence of many industries.
Stainless Steel 317L Sheets and Plates are austenitic stainless steels composed mainly of chromium (18–20%), nickel (11–15%), and molybdenum (3–4%), which enhances their corrosion resistance in aggressive chemical environments. The “L” marking denotes low carbon content, which serves to reduce carbide precipitation while welding. These sheets and plates deliver a tensile strength of approximately 515 MPa, together with outstanding ductility, toughness, and strong resistance to pitting, crevice, and general corrosion. They also offer good weldability, formability, and thermal stability, which makes them well-suited for a broad range of industrial applications.
| 317L Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 317L Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 317L Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 317L Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 317L Stainless Steel Sheet 3.0–10.0 mm |
| 317L SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 317L Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 317L Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 317L Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 317L Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 317L SS Strips EN 10088 SA -240-304 / 317L Strips |
| Finish of SS 317L Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| 2000MM X 1000MM X 3MM | 2000MM X 1000MM X 6MM |
| 2500MM X 1250MM X 4MM | 2500MM X 1250MM X 8MM |
| 3000MM X 1500MM X 3MM | 3000MM X 1500MM X 6MM |
| 3000MM X 1500MM X 4MM | 3000MM X 1500MM X 8MM |
| 2000MM X 1000MM X 5MM | 2500MM X 1250MM X 10MM |
| 2500MM X 1250MM X 3MM | 2500MM X 1250MM X 6MM |
| 4000MM X 2000MM X 3MM | 4000MM X 2000MM X 6MM |
| 2500MM X 1250MM X 5MM | 3000MM X 1500MM X 10MM |
| 2000MM X 1000MM X 4MM | 2000MM X 1000MM X 8MM |
| 4000MM X 2000MM X 4MM | 2000MM X 2000MM X 10MM |
| 3000MM X 1500MM X 5MM |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Stainless steel 317L sheets and platesoffer numerous benefits, including outstanding corrosion resistance, particularly in high chloride settings Their low carbon content improves weldability, prevents carbide precipitation and delivers good welding strength after the. They demonstrate excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, making them well suited for chemically complex marine environments 317L also retains excellent tensile strength, rigidity and formability at temperature in a higher order. These characteristics make them well suited for use in industries such as the chemical industry, pharmaceutical manufacturing, marine and food processing, where durability and reliability are critical.
Stainless Steel 317L Sheets and Plates are widely applied across the chemical processing, petrochemical, marine, and pharmaceutical sectors. They work exceptionally well for building storage tanks, heat exchangers, chemical reactors, pressure vessels, and piping systems exposed to severely corrosive environments. On top of that, they serve in seawater applications, pulp and paper equipment, and food processing machinery, where standing up to chloride attack and general corrosion is critical. Their combination of toughness, corrosion resistance, and strong mechanical performance guarantees dependable service even in tough industrial and environmental conditions.
