Al Shakru Sheets and Plates, a highly regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Stainless Steel 304H Sheets and Plates engineered to withstand the demands of high-temperature and high-pressure industrial applications. Known for their exceptional corrosion resistance, strength, and durability, these sheets and plates are ideal for use in demanding environments. Al Shakru Sheets and Plates takes pride in guaranteeing that each product is manufactured with accuracy, complying with international quality and performance standards. With a strong commitment to reliability and customer satisfaction, the company provides Stainless Steel 304H solutions designed to serve a wide range of industrial and engineering requirements.
Stainless Steel 304H is a high-carbon version of the 304 grade, containing 18–20% Chromium, 8–10.5% Nickel, and an elevated carbon level of 0.04–0.10%, which enhances its strength and thermal resistance. It offers a tensile strength of approximately 515–750 MPa, a yield strength of around 205 MPa, and an elongation of about 40%. This material performs exceptionally well in oxidation resistance and maintains its structural integrity even under high temperatures, making it an excellent choice for high-temperature service applications.
| ASTM Specification | ASTM A240 / ASME SA240 |
|---|---|
| Standard | MSRR, AMS, BS, ASTM A240 / ASME SA240 |
| Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, 4′ x 8′, Cut to size available |
| Thickness | 0.1mm to 100 mm Thk |
| Width | 10-2500mm |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Temper | Annealed |
| Condition | Polished on both sides |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Stock in form of | Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Test Report |
|
| Profiling | To provide a full profiling service we use numerous profiling methods including:
|
| Specialized in |
|
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304H | 0.10 max | 2.0 max | 0.75 max | 0.045 max | 0.03 max | 18 – 20 | – | 8 – 10.5 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 304H | 1.4948 | S30409 |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Stainless steel 304H sheets and platesoffer numerous advantages, including outstanding corrosion resistance, which makes them perfect for demanding environments. Thanks to their strength and durability, they are well matched to high temperature applications, particularly in sectors such as fuel and power generation. The material has strong resistance to oxidation and scaling, delivering durability and reliability. Their ease of fabrication, forming, and weldability enable them to serve in a range of architectural and industrial applications. Additionally, 304H provides outstanding resistance to chloride-induced stress corrosion cracking, making it a superb choice for demanding conditions
Stainless Steel 304H Sheets and Plates are widely applied across industries that require outstanding heat resistance and mechanical strength. Typical uses include heat exchangers, boilers, pressure vessels, chemical processing equipment, oil and gas refineries, and power generation plants. They are also utilized in furnace components, piping systems, and structural parts subjected to high temperatures. Their impressive capacity to withstand oxidation and corrosion under severe conditions makes them a perfect selection for essential engineering and thermal applications. Al Shakru Sheets and Plates supplies these sheets and plates to ensure dependability and durable performance.
