The SA 515 Grade 60 Sheets and Plates consist mainly of carbon (up to 0.24%), manganese (0.55–0.98%), phosphorus (0.035%), sulfur (0.035%), and silicon (0.13–0.45%). These plates offer a minimum tensile strength between 415 and 550 MPa along with a yield strength of 220 MPa, which makes them well suited for high-temperature applications. Thanks to their outstanding weldability, formability, and impact resistance, they retain their structural integrity and durability even under demanding operating conditions.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
| |
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 60 | 0.24-0.31 | 0.98 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Thickness | Yield | Tensile | Elongation |
|---|---|---|---|---|
| A515 Grade 60 | 50-200mm | MPa -220 min | MPa – 415-550 | 21-25% |
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our extensive inventory includes Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
SA 515 Grade 60 sheets and platesoffer numerous benefits, such as superb strength, durability, and the ability to withstand elevated temperatures and pressure, which makes them well-suited for boilers, pressure vessels, and heat exchangers. Their remarkable weldability and formability guarantee straightforward fabrication and installation. These materials also deliver good machinability and lasting performance, even in tough environments. Thanks to their capacity to endure thermal stress and corrosion, SA 515 Grade 60 sheets and plates are a dependable option for industries that need safe and efficient operation under demanding conditions.
Yes,we provide custom dimensions for ASTM SA 515 grade 60 Sheets and Plates to fit particular project requirements. The team here at Al Shakru Sheets and Plates is committed to delivering tailored solutions for every one of your needs. To learn more, reach out to us at sales@alshakruplates.ae.
Industries demanding high performance at elevated temperatures and pressures make extensive use of SA 515 Grade 60 Sheets and Plates. They are ideal for building boilers, pressure vessels, heat exchangers, and storage tanks in oil refineries, petrochemical plants, and power generation facilities. Thanks to their exceptional mechanical properties and resistance to deformation, these plates are indispensable in applications where reliability, safety, and durability are critical. Their excellent weldability and toughness also make them favored options in construction, engineering, and heavy fabrication projects.
