In terms of composition, ASTM A537 Sheets and Plates are primarily made up of carbon (0.25–0.28%) , manganese (0.70–1.00%) , phosphorus (≤0.035%) , sulfur (≤0.040%) , together with small quantities of silicon and chromium . These plates deliver impressive tensile strength (minimum 485 MPa) , yield strength (minimum 275 MPa) , and outstanding impact toughness . They are engineered for superb weldability, machinability, and formability , which makes them well suited for heavy-duty fabrication and applications requiring high structural integrity and dependability under pressure.
| Condition | normalized |
| grade | ASTM A537 Cl 1 |
| sizes |
|
| Manufacturing method | Hot Rolled |
| certificates | EN 10204 3.1/2.2 |
| Brands | Thyssen, JSPL, Essar, JSW, POSCO, Clabecq, TATA, Dillinger, Uttam, SAIL |
| Uses |
|
| Surface | Painted, Natural |
| TPI | DNV, CE, TUV, KR, CCS, RINA, LR, GL, ABS |
| Mn | 0.70-1.60% |
| C | 0.24% |
| S Max. | 0.025% |
| Ph Max. | 0.025% |
| CU Max. | 0.35% |
| Si | 0.15-0.50% |
| CR Max. | 0.25% |
| NI Max. | 0.25% |
| MOLY Max. | 0.08% |
| Heat Treatment | Class | Thickness | Tensile Strength, minimum, ksi [MPa] | Yield Strength, minimum, ksi [MPa] |
|---|---|---|---|---|
| Q & T | Class 3 | 21/2 in. & under [65 milimeter and under] | 80 ksi [550] | 55 ksi [380] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 40 ksi [275] | ||
| Over 21/2 to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 50 ksi [345] | ||
| Q & T | Class 2 | 21/2 inch and under [65 milimeter and under] | 80 ksi [550] | 60 ksi [415] |
| Over 4 inch [Over 100 milimeter] | 70 ksi [485] | 46 ksi [315] | ||
| Over 21/2 to 4 inch [Over 65 to 100 milimeter] | 75 ksi [515] | 55 ksi [380] | ||
| Normalized | Class 1 | 21/2 inch and under [65 milimeter and under] | 70 ksi [485] | 50 ksi [345] |
| Over 21/2 inch [Over 65 milimeter] | 65 ksi [450] | 45 ksi [310] |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on delivering high-grade products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
ASTM A537 sheets and platesprovide numerous benefits, such as outstanding strength and durability, which make them well-suited for high-pressure and high-temperature uses like pressure vessels and boilers. They offer excellent weldability, permitting straightforward fabrication and joining. Their resistance to impact guarantees dependability even in severe environments. Moreover, the heat-treated characteristics improve their toughness, allowing them to endure extreme conditions without sacrificing performance. Combining corrosion resistance with great formability, ASTM A537 plates provide durable, dependable performance in tough industrial settings, ensuring safety and efficiency.
Yes,we provide custom sizes for ASTM A537 Sheets and Plate to suit particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. To learn more, reach out to us at sales@alshakruplates.ae.
You’ll commonly see ASTM A537 Sheets and Plates put to work in pressure vessels, storage tanks, boilers, and heat exchangers , owing to their solid strength and their capacity to endure stress and pressure. Within the world of heavy engineering and construction , they serve a vital function in structural components, machinery bases, and industrial equipment . On top of that, these plates prove indispensable across the oil and gas, petrochemical, and manufacturing industries , where durability, toughness, and safety are of the utmost importance. Their distinctive combination of mechanical strength, corrosion resistance, and weldability establishes ASTM A537 Sheets and Plates as the preferred pick for high-performance industrial and structural applications .
