SA 515 Grade 70 Sheets and Plates are manufactured from carbon steel, generally comprising 0.27–0.31% carbon, 0.60–0.90% manganese, together with small quantities of phosphorus, sulfur, and silicon. These elements help deliver their remarkable strength, ductility, and ability to withstand deformation under pressure. The plates offer a minimum tensile strength of 485–620 MPa and a yield strength of roughly 260 MPa. On top of this, SA 515 Grade 70 Sheets and Plates exhibit solid notch toughness and weldability, which makes them well suited for pressure-bearing uses that call for high thermal stability.
| Specifications | ASTM A515 Gr. 70 / ASME A515 Grade 70 | |
| Thickness |
|
|
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 70 | 0.30-0.35 | 1.30 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Yield | Tensile | Thickness | Elongation |
|---|---|---|---|---|
| A515 Grade 70 | MPa -551 min | MPa – 485-620 | 50-200mm | 17-21% |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying first-rate products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and excellent products.
SA 515 Grade 70 sheets and platesprovide many benefits, making them well-suited for demanding applications. They deliver outstanding strength and durability, guaranteeing reliability in high-pressure and high-temperature settings. Thanks to their excellent weldability, these plates are simple to fabricate and incorporate into complex structures. Their resistance to cracking and mechanical stress improves safety and longevity, even in extreme conditions. The material’s flexibility enables its use across a range of industries, such as power generation, petrochemical, and construction. On top of that, their consistent quality and performance make them an economical option for critical projects.
Yes,we provide custom sizes for ASTM SA 515 grade 70 Sheets and Plates to suit particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
These plates find broad application across industries operating under high pressure and temperature conditions. Their main use lies in fabricating boilers, heat exchangers, pressure vessels, and storage tanks. Within sectors such as oil, gas, and power generation, these plates are vital for components required to maintain durability and strength when subjected to cyclic loading and thermal stress. Because they can resist high temperatures, they are well suited for steam processing systems and chemical plants. In the end, SA 515 Grade 70 Sheets and Plates ensure extended service life, dependability, and safety in demanding industrial operations.
