Al Shakru Sheets and Plates is a well-regarded manufacturer and supplier based in Dubai, UAE, specializing in premium Inconel 600 Angles designed for industrial uses that demand exceptional performance. Known for their accuracy, dependability, and advanced production methods, the company produces materials engineered to withstand harsh conditions, including elevated temperatures, oxidation, and corrosive surroundings. Their Inconel 600 Angles deliver outstanding durability, strength, and structural soundness, making them ideal for essential projects. Serving industries such as aerospace, chemical processing, power generation, and marine, Al Shakru Sheets and Plates offers tailored solutions that ensure sustained operational efficiency, steady quality, and reliable performance in demanding industrial environments.
Inconel 600 Angles are composed primarily of nickel and chromium, with iron added to enhance mechanical strength and corrosion resistance. This alloy demonstrates high tensile and yield strength, exceptional creep and rupture resistance, and good ductility over a wide temperature range. Inconel 600 stays stable under thermal cycling and severe chemical exposure, offering resistance to oxidation, pitting, and stress corrosion cracking. On top of that, the material features excellent weldability and formability, making it well suited for applications that require both mechanical durability and dependable long-term performance in demanding industrial environments.
Specifications :ASTM B166 / ASME SB166
Angle Size Range :20 x 20 mm to 100 x 100 mm
Angles Thickness :3 to 12 mm (varies by size)
Channel Size Range :Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness :5 to 6 mm (varies by size)
Length :3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Lengths
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Element | Ni | C | Mn | Cu | S | Si | Cr | Fe |
| Inconel 600 | 72.0 min | 0.15 max | 1.0 max | 0.5 max | 0.015 max | 0.5 max | 14.0 – 17.0 | 6.0 – 10.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness (Brinell) |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % | – |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on delivering exceptional products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory includes Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Inconel 600 Angleprovides numerous benefits, such as outstanding resistance to oxidation and corrosion, especially in high-temperature settings. Its capacity to endure extreme temperatures reaching 2,000°F (1,093°C) makes it well-suited for use in sectors like aerospace, chemical processing, and power generation. The alloy demonstrates significant strength and durability, retaining its mechanical properties even when subjected to stress. Furthermore, Inconel 600 offers strong resistance to sulfur compounds and chloride stress corrosion cracking, guaranteeing lasting performance and dependability. These characteristics make it a favored material for challenging and severe environments.
Yes,we provide custom sizes for Inconel 600 Angle to fit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your requirements. For further information, reach out to us at sales@alshakruplates.ae.
| Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) | Inconel Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Inconel 600 Angles are widely applied across industries that demand corrosion resistance and stability at high temperatures. Within aerospace, they serve in exhaust systems, turbine components, and heat shields. The chemical and petrochemical fields rely on them for reactors, piping, and heat exchangers. Power generation plants incorporate these angles into boiler components, superheaters, and furnace linings, whereas marine uses include seawater handling systems and offshore structures. Because of their outstanding mechanical strength, durability, and resistance to oxidation, they remain a preferred option for challenging environments.
