Al Shakru Sheets and Plates, based in Dubai, UAE, distinguishes itself as a premier manufacturer and supplier of high-quality Titanium Angles . Known for its precision engineering and rigorous quality control, this company produces items that deliver outstanding strength, corrosion resistance, and durability. Their Titanium Angles are made using advanced manufacturing methods, guaranteeing dimensional accuracy and steady performance across many different applications. Serving sectors such as aerospace, chemical processing, marine, and medical, Al Shakru Sheets and Plates supplies Titanium Angles that satisfy the most demanding operational requirements. Designed for enduring reliability and superior performance, these angles offer both structural integrity and lightweight advantages for essential engineering and industrial projects.
The Titanium Angles from Al Shakru Sheets and Plates are crafted from commercially pure titanium or titanium alloys, delivering remarkable corrosion resistance and a high strength-to-weight ratio. In terms of mechanics, they demonstrate outstanding tensile strength, fatigue resistance, and toughness over a wide temperature range. Both lightweight and exceptionally strong, these angles are simple to shape, weld, and keep structurally stable, which makes them ideal for building intricate components. Their distinctive combination of mechanical properties and chemical stability guarantees that Titanium Angles provide lasting performance in demanding environments, making them a reliable option for both industrial and specialized uses.
Dimensions: ASME, ASTM, EN, BS, GB, DIN, JIS, etc
Size : Angle Size : 3/4″ THRU 8″
Channel Size : Base: 80 to 150 mm Side: 40 to 75 mm
Thickness: Angle Thickness: 1/8″ thru 5/8″
Channel Thickness : Base: 5 to 6 mm (as per size)
Angle Length: Length up to 6 Meters
Processing: Bar Cutting
Application: Paper Industry, Architucture, Construction, Kitchen Equipment, Pharma, Engineering Industries And Many More
Angle Types: Angles, Angle Bars, Equal Angle, Unequal Angle, L Shape Angles, Equal Leg Angle, Unequal Leg Angle, T Shaped Angle
Channel Types: Channel, Channel Bars, C-channel, U-Channel, Strut Channels, Miscellaneous Channel, MC Channels, Unistrut Channels
We supply materials that are accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates based in Dubai, UAE, is a premier supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to satisfy our customers specific needs. With an emphasis on delivering exceptional products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Titanium anglesprovide many benefits, such as an outstanding strength-to-weight ratio, which makes them perfect for uses where cutting down on weight is essential. They offer strong resistance to corrosion, even in demanding settings like the marine and chemical industries, guaranteeing durability and lower maintenance expenses. Titanium angles also hold up well at high temperatures without sacrificing strength, making them appropriate for aerospace and industrial uses. On top of that, they have great fatigue and impact resistance, ensuring they last under stress. Their non-reactive quality also renders them biocompatible, which is advantageous for medical and surgical uses. All in all, titanium angles deliver unrivaled reliability and performance.
| Sizes (all Dimensions in milimeter) | Approx Weight Titanium Angle Bar (kilogram/meter) | Titanium Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Titanium Alloy Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes,we offer custom sizes for Titanium Angle to fit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your requirements. For more information, reach out to us at sales@alshakruplates.ae.
Titanium Angles find broad use across numerous industries owing to their strength, resistance to corrosion, and adaptability. Within aerospace, they serve a vital function in structural frameworks, support parts, and engine assemblies where reducing weight while boosting strength is critical. The chemical and petrochemical sectors depend on them for corrosion-resistant structures, piping supports, and equipment frameworks. For marine uses, they are essential in shipbuilding and offshore structures, and the medical field gains from their dependability in specialized equipment.
