Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, focuses on high-quality Nickel Alloy 201 Sheets and Plates . These products are engineered for exceptional corrosion resistance, mechanical strength, and performance under high temperatures. Manufactured to meet rigorous international standards, these sheets and plates deliver impressive durability, thermal stability, and precise dimensional accuracy. Al Shakru Sheets and Plates uses advanced production techniques together with comprehensive quality control to deliver dependable, high-performance nickel alloy solutions. They serve numerous industries, such as chemical processing, aerospace, electronics, and marine engineering, providing Nickel Alloy 201 Sheets and Plates that are ideal for critical applications where resistance to harsh environments, oxidation, and long-term reliability are essential.
Nickel Alloy 201 Sheets and Plates are chiefly composed of high-purity nickel (≥99.6%), along with minor quantities of iron, copper, carbon, and silicon. They feature a tensile strength of roughly 370 MPa, a yield strength of 100 MPa, and remarkable ductility. These sheets and plates provide outstanding corrosion resistance in both reducing and caustic settings, retain their mechanical strength at high temperatures, and supply good thermal and electrical conductivity. Their combination of toughness, formability, and stability makes them well suited for challenging industrial and high-performance uses.
| Grade | Nickel Alloy 201 | UNS N02201 |
| Standard | ASTM B162 / ASME SB162 |
| Size | 1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm, 2010 mm x 4000 mm |
| Thickness | 0.1mm To 100 mm |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | Sheets, Plates, Plain Sheet, Shim Sheet, Strip, Flats |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Our products are supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Nickel Alloy 201 Sheets and Plates deliver outstanding corrosion resistance, especially in acidic and alkaline conditions. They exhibit strong resistance to oxidation and feature exceptional thermal and electrical conductivity. These alloys are recognized for their remarkable formability, enabling straightforward shaping and welding. Boasting excellent mechanical properties at both high and low temperatures, Nickel Alloy 201 is well-suited for chemical processing, heat exchangers, and electronics applications. It also delivers strength and stability, making it appropriate for demanding environments and high-stress applications.
|
Nickel 201 plate Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.134″ |
3.40 |
|
.125″ |
3.18 |
|
.187″ |
4.75 |
|
.156″ |
3.96 |
|
.312″ |
7.92 |
|
.250″ |
6.35 |
|
.500″ |
12.7 |
|
.375″ |
9.53 |
|
.600″ |
15.9 |
|
.875″ |
22.2 |
|
.750″ |
19.1 |
|
1″ |
25.4 |
|
3″ |
76.2 |
|
1.250″ |
31.8 |
|
1.125″ |
28.6 |
|
1.500″ |
38.1 |
|
2″ |
50.8 |
|
1.750″ |
44.5 |
|
2.500″ |
63.5 |
Nickel Alloy 201 Sheets and Plates are widely applied in sectors demanding strong corrosion resistance, thermal stability, and mechanical strength. They are frequently used in chemical processing equipment, caustic evaporators, and reaction vessels . Within the electronics and aerospace sectors , they function in batteries, electrical connectors, and high-temperature structural components . Their outstanding behavior in caustic, reducing, and high-temperature conditions further makes them well-suited for marine, petrochemical, and medical applications .
