Al Shakru Sheets and Plates, a first-rate manufacturer and supplier based in Dubai, UAE, focuses on premium Nickel Alloy 200 Sheets and Plates . These products are engineered to deliver exceptional corrosion resistance, mechanical strength, and high-temperature performance. Built to comply with rigorous international standards, these sheets and plates feature accurate dimensions, an excellent surface finish, and reliable durability, making them ideal for challenging industrial applications. Al Shakru Sheets and Plates uses advanced manufacturing techniques together with rigorous quality control to deliver trustworthy nickel alloy solutions. They serve a range of industries, such as chemical processing, marine, aerospace, and electronics, providing Nickel Alloy 200 Sheets and Plates that perform well in caustic, oxidizing, or thermally stressed conditions, all while guaranteeing durable performance.
Nickel Alloy 200 Sheets and Plates are chiefly composed of high-purity nickel (≥99.0%), along with minor quantities of iron, copper, carbon, and silicon. They exhibit tensile strength ranging from 380–500 MPa, yield strength of 100–300 MPa, and outstanding ductility. These sheets and plates offer superior corrosion resistance in both reducing and caustic settings, hold their form at high temperatures, and supply good thermal and electrical conductivity. Their combination of toughness, formability, and durability at elevated temperatures makes them ideal for demanding industrial and chemical applications.
| Specification | ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| standards and approvals |
|
| Plasma profiles | As per customer’s drawings |
| Value added services | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| VAS |
|
| Packing | Bundles with waterproof cloth outside or plywood box |
| Test | UT, SGS testing, TUV etc |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | —2 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Nickel Alloy 200 sheets and plates deliver outstanding corrosion resistance, especially against alkalis, acids, and other severe environments. Recognized for their superb weldability and formability, they retain solid mechanical properties across both low and high temperatures. The alloy demonstrates high strength and durability, which makes it perfect for chemical processing, aerospace, and marine uses. Its outstanding thermal and electrical conductivity guarantees dependable performance across a range of industrial applications. Its non-magnetic characteristics further enhance its versatility, particularly in sensitive equipment.
| Nickel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874″) x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135″) x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120″) x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120″) x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120″) x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120″) x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120″) x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105″) x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105″) x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105″) x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075″) x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075″) x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060″) x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060″) x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060″) x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060″) x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048″) x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048″) x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036″) x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036″) x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030″) x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030″) x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030″) x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024″) x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024″) x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018″) x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018″) x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015″) x 36 x 120 | .6300 | 18.90 |
Nickel Alloy 200 Sheets and Plates are widely applied across industries that require strong corrosion resistance, thermal stability, and reliable mechanical performance. They are frequently employed in chemical processing equipment, caustic evaporators, and reaction vessels . Within the marine and aerospace industries , they function as structural components, electrical connectors, and parts for high-temperature machinery . Their remarkable ability to withstand oxidation, caustic conditions, and thermal stress also makes them well suited for petrochemical applications and industrial machinery .
