Al Shakru Sheets and Plates, a respected manufacturer and supplier based in Dubai, UAE, specializes in delivering high-quality Titanium Grade 5 Coils and Slitting Coils that meet international industrial standards. Renowned for their exceptional strength, corrosion resistance, and lightweight properties, these coils are engineered for high-performance applications in demanding conditions. Al Shakru Sheets and Plates ensures accurate manufacturing, a superior surface finish, and dependable quality across every product they supply. Their Titanium Grade 5 Coils and Slitting Coils are trusted throughout numerous industries, including aerospace, marine, chemical, and medical, owing to their dependability, longevity, and outstanding performance in essential engineering and structural applications.
These Titanium Grade 5 Coils and Slitting Coils consist of roughly 90% titanium, 6% aluminum, and 4% vanadium, forming a high-strength, heat-treatable alloy. They demonstrate excellent tensile and yield strength, superb resistance to corrosion and oxidation, and an impressive strength-to-weight ratio. They also retain mechanical stability at elevated temperatures and provide good weldability and formability. The combination of aluminum and vanadium enhances the alloy’s fatigue resistance, making it well suited for both high-pressure and high-stress applications.
| Standards | ASTM B265 / ASME SB265 |
| Thickness | 0.2mm – 5.0mm |
| Width | 3.2mm – 1500mm & bove |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, AS PER CUSTOMER’S REQUIREMENT |
| Hardness | Annealed – pickled (soft), Soft, Hard, Half Hard, Quarter Hard, Spring Hard , 1/4 hard, Yi hard,3/4 hard , full hard , extra hard |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | Cold rolled stainless steel strips annealed & pickled 2 B Cold rolled stainless steel strips annealed & skin passed 2R Work harden for specific hardness BA/BE/ Matt Finish Cold rolled stainless steel strips |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Ti Gr.5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr.5 | 3.7165 | R56400 |
We supply products that are accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, delivering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
| Thickness Tolerance +/- mm | ||||
| Thickness | Width | |||
| 320≤W＜600 | W＜320 | |||
| T1 | T2 | T3 | T4 | |
| T＜0.05 mm | 0.004 | 0.003 | 0.003 | 0.002 |
| 0.05≤T＜0.07 | 0.005 | 0.004 | 0.004 | 0.003 |
| 0.07≤T＜0.08 | 0.006 | 0.005 | 0.005 | 0.003 |
| 0.08≤T＜0.10 | 0.007 | 0.005 | 0.005 | 0.003 |
| 0.10≤T＜0.13 | 0.009 | 0.007 | 0.006 | 0.004 |
| 0.13≤T＜0.15 | 0.010 | 0.008 | 0.007 | 0.004 |
| 0.15≤T＜0.20 | 0.011 | 0.009 | 0.008 | 0.004 |
| 0.20≤T＜0.25 | 0.013 | 0.010 | 0.008 | 0.005 |
| 0.25≤T＜0.30 | 0.015 | 0.011 | 0.009 | 0.005 |
| 0.30≤T＜0.35 | 0.016 | 0.012 | 0.010 | 0.005 |
| 0.35≤T＜0.40 | 0.018 | 0.012 | 0.010 | 0.005 |
| 0.40≤T＜0.50 | 0.020 | 0.015 | 0.012 | 0.005 |
| 0.50≤T＜0.60 | 0.022 | 0.018 | 0.013 | 0.005 |
| 0.60≤T＜0.70 | 0.024 | 0.020 | 0.015 | 0.005 |
| 0.70≤T＜0.80 | 0.026 | 0.022 | 0.017 | 0.005 |
| 0.80≤T＜0.90 | 0.028 | 0.024 | 0.018 | 0.006 |
| 0.90≤T＜1.00 | 0.032 | 0.027 | 0.020 | 0.008 |
| 1.00≤T＜1.20 | 0.035 | 0.030 | 0.022 | 0.008 |
| 1.20≤T＜1.40 | 0.040 | 0.035 | 0.025 | 0.010 |
| 1.40≤T＜1.60 | 0.045 | 0.040 | 0.030 | 0.020 |
Titanium Grade 5 coils and slitting coilsoffer numerous advantages, such as a high strength to weight ratio, outstanding corrosion resistance, and remarkable durability They endure severe conditions, including temperatures reaching up to 400 degrees Celsius itself without any drop in performance. Their biocompatibility makes them well suited for medical uses, while their light weight boosts fuel efficiency in the aerospace and automotive sectors. These coils also demonstrate strong fatigue and separation resistance, ensuring a long service life. Moreover, they are adaptable, simple to machine, and reusable, delivering durable and dependable solutions for demanding applications across many different industries.
Yes,we provide custom sizes for Titanium Grade 5 Coil/Slitting Coil to suit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your requirements. For further information, reach out to us at sales@alshakruplates.ae.
Titanium Grade 5 Coils and Slitting Coils are commonly seen across industries that call for high strength and resistance to corrosion while keeping weight as low as possible. Within aerospace, they serve in aircraft components, engine casings, and structural panels. The marine industry relies on them for shipbuilding, offshore platforms, and propeller shafts thanks to their capacity to endure seawater. In chemical processing, they play a critical role in heat exchangers and reactors, whereas in the medical sector, they go into surgical instruments and implants. These coils also prove worthwhile in the automotive and power generation fields, delivering efficient and durable performance.
