Al Shakru Sheets and Plates is a dependable manufacturer and supplier based in Dubai, UAE, specializing in high-performance metal products. Among our leading offerings are Titanium Grade 2 Sheets and Plates, recognized for their outstanding corrosion resistance, durability, and lightweight properties. We cater to numerous industries, including aerospace, marine, medical, and chemical processing. Our commitment to quality, timely delivery, and customer satisfaction has made us a trusted source for Titanium Grade 2 solutions across UAE. At Al Shakru Sheets and Plates, we guarantee that all of our titanium products meet international standards and are tailored to fulfill the particular requirements of our clients.
Titanium Grade 2 Sheets and Plates are fabricated from commercially pure titanium, generally comprising 99.2% titanium together with small quantities of iron (0.3%), oxygen (0.25%), carbon, nitrogen, and hydrogen. They deliver an excellent combination of moderate strength, ductility, and weldability. The mechanical properties feature a tensile strength of roughly 344 MPa, yield strength of 275 MPa, and an elongation of approximately 20%. Owing to their low density of 4.51 g/cm³, they are ideal for uses that demand a high strength-to-weight ratio. Their remarkable resistance to corrosion, especially in oxidizing and aqueous conditions, renders them exceptionally versatile.
| Specifications | ASTM B265/ ASME SB265 |
|---|---|
| Size | 1000 x 2000 milimeter, 1220 x 2440 milimeter, 1500 x 3000 milimeter, 2000 x 2000 milimeter, 2000 x 4000 milimeter |
| Thickness | 0.1 to 12 milimeter |
| Form | Plates, Sheet, Slatting Coils, Coils, Foils, Plain Sheet, Shim Sheet, Strip, Rolls, Perforated Coils, Flats, Blank , Ring |
| Finish | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade | Ti | C | Fe | H | N | O | Al | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade 2 Sheet & Plate | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 2 Sheet & Plate | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Titanium Grade 2 sheets and plates deliver outstanding corrosion resistance, especially in marine and chemical settings, which makes them well suited for the aerospace, chemical processing, and marine industries. Despite being lightweight, they are remarkably strong, offering a high strength-to-weight ratio. Valued for their biocompatibility, they see extensive use in medical applications. Titanium Grade 2 additionally features good weldability, formability, and resistance to elevated temperatures, making it adaptable across a range of uses. Moreover, it displays low thermal expansion, improving stability in demanding environments.
| Stocked Sizes | |
|---|---|
| Size (in inches) | Size (in ) |
| .125 | 3.18 |
| .134 | 3.40 |
| .156 | 3.96 |
| .187 | 4.75 |
| .250 | 6.35 |
| .312 | 7.92 |
| .375 | 9.53 |
| .500 | 12.7 |
| .600 | 15.9 |
| .750 | 19.1 |
| .875 | 22.2 |
| 1 | 25.4 |
| 1.125 | 28.6 |
| 1.250 | 31.8 |
| 1.500 | 38.1 |
| 1.750 | 44.5 |
| 2 | 50.8 |
| 2.500 | 63.5 |
| 3 | 76.2 |
Titanium Grade 2 Sheets and Plates find widespread use throughout many industries thanks to their outstanding corrosion resistance and remarkable strength-to-weight ratio. Within the aerospace field, they serve in airframes, engine components, and structural parts. The marine industry uses them in desalination systems and ship components exposed to seawater. In medical environments, they are preferred for surgical instruments and implants owing to their biocompatibility. In addition, chemical processing plants rely on them for heat exchangers and pressure vessels. Their formability and weldability further make them well-suited for architectural applications and high-performance automotive parts.
