Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on high-quality Nimonic 80A Sheets and Plates ideally suited for high-temperature and corrosion-resistant applications. Recognized for their exceptional strength, creep resistance, and durability, these nickel-chromium-cobalt alloy sheets and plates are engineered to comply with rigorous international standards. By combining advanced manufacturing techniques with comprehensive quality control, Al Shakru Sheets and Plates makes certain that their products remain dependable and uniform. Serving industries such as aerospace, power generation, and chemical processing, the company assures that its Nimonic 80A Sheets and Plates provide superior performance, long service life, and accuracy, making them the preferred selection for challenging industrial and engineering requirements.
Nimonic 80A Sheets and Plates are primarily made up of nickel (around 77%), chromium (about 19%), cobalt (approximately 1.5%), titanium (nearly 0.8%), and aluminum (roughly 0.6%). This high-performance alloy demonstrates remarkable mechanical properties, featuring a tensile strength of around 850–900 MPa along with outstanding creep and fatigue resistance at high temperatures reaching up to 750°C. Furthermore, Nimonic 80A provides superb oxidation and corrosion resistance, preserving its form and structural integrity even under severe thermal and mechanical stress, which makes it a perfect choice for demanding high-temperature applications.
| Standards : | ASTM B637 / ASME SB637 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets and Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets and Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
We supply products that include both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, headquartered in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Nimonic 80A sheets and platesprovide numerous benefits, making them well-suited for high-performance applications. They deliver outstanding heat and oxidation resistance, retaining strength at elevated temperatures up to 900°C. The alloy’s excellent creep and fatigue resistance guarantee durable performance in demanding environments. Nimonic 80A also demonstrates superior corrosion resistance, particularly in high-temperature and severe conditions, making it appropriate for aerospace, gas turbines, and industrial applications. Its high tensile and yield strength, together with good weldability, boost its versatility and dependability in critical components exposed to extreme stress.
| WEIGHT PER NIMONIC SHEET : | ||||
| THICKNESS IN MM | SIZE IN MM | WEIGHT KG/M2 | ||
| 2000 X 1000 | 2500 X 1250 | 3000 X 1500 | ||
| 0.18 | 2.88 | – | – | 1.44 |
| 0.20 | 3.20 | – | – | 1.60 |
| 0.22 | 3.52 | – | – | 1.76 |
| 0.24 | 3.84 | – | – | 1.92 |
| 0.27 | 4.32 | – | – | 2.16 |
| 0.28 | 4.48 | – | – | 2.24 |
| 0.32 | 5.12 | – | – | 2.56 |
| 0.38 | 6.08 | – | – | 3.04 |
| 0.44 | 7.04 | 11.00 | – | 3.52 |
| 0.50 | 8.00 | 12.50 | – | 4.00 |
| 0.56 | 8.96 | 14.00 | – | 4.48 |
| 0.63 | 10.08 | 15.75 | – | 5.04 |
| 0.75 | 12.00 | 18.75 | – | 6.00 |
| 0.88 | 14.08 | 22.00 | – | 7.04 |
| 1.00 | 16.00 | 25.00 | 36.00 | 8.00 |
| .1.13 | 18.08 | 28.25 | 40.00 | 9.04 |
| 1.25 | 20.00 | 31.25 | 45.00 | 10.00 |
| 1.38 | 22.03 | 34.50 | 50.00 | 72.00 |
| 1.50 | 24.00 | 37.50 | 54.00 | 12.00 |
| 1.75 | 28.00 | 43.75 | 63.00 | 14.00 |
| 2.00 | 32.00 | 50.00 | 72.00 | 16.00 |
| 2.25 | 36.00 | 56.25 | 81.00 | 18.00 |
| 2.50 | 40.00 | 62.50 | 90.00 | 20.00 |
| 2.75 | 44.00 | 68.75 | 99.00 | 22.00 |
| 3.00 | 48.00 | 75.00 | 108.00 | 24.00 |
| 3.25 | 52.00 | 81.25 | 117.00 | 26.00 |
| 3.50 | 56.00 | 87.50 | 126.00 | 28.00 |
| 3.75 | 60.00 | 93.75 | 135.00 | 30.00 |
| 4.00 | 64.00 | 100.00 | 144.00 | 32.00 |
| 4.25 | 68.00 | 106.25 | 153.00 | 34.00 |
| 4.50 | 72.00 | 112.50 | 162.00 | 36.00 |
| 5.00 | 80.00 | 125.00 | 180.00 | 40.00 |
| 5.50 | 88.00 | 137.50 | 198.00 | 44.00 |
| 6.00 | 96.00 | 150.00 | 216.00 | 48.00 |
| 6.50 | 104.00 | 162.50 | 234.00 | 52.00 |
| 7.00 | 112.00 | 175.00 | 252.00 | 56.00 |
| 7.50 | 120.00 | 187.50 | 270.00 | 60.00 |
| 8.00 | 128.00 | 200.00 | 288.00 | 64.00 |
Yes,we provide custom sizes for Nimonic 80A Sheets and Plates to suit particular project requirements. The team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
Nimonic 80A Sheets and Plates are widely applied across industries demanding high-temperature strength, resistance to corrosion, and lasting durability. They are commonly employed in aerospace turbine components, jet engine parts, and gas turbines . Within the power generation industry , they function in boiler components, heat exchangers, and high-temperature structural elements . Their exceptional creep resistance and thermal stability also render them well-suited for chemical processing equipment, furnace components, and aerospace structural parts . Nimonic 80A Sheets and Plates deliver reliable performance even in the toughest environments.
