Al Shakru Sheets and Plates, an outstanding manufacturer and supplier based in Dubai, UAE, focuses on premium Nickel Alloy 201 Foils engineered to deliver superior performance in demanding, corrosive, and high-temperature conditions. These foils are produced according to international standards, offering impressive purity, notable mechanical properties, and excellent resistance to chemicals and oxidation. At Al Shakru Sheets and Plates, precise manufacturing takes priority, guaranteeing uniform thickness and an excellent surface finish to meet a wide range of industrial requirements. The company proudly caters to industries such as chemical processing, electronics, and marine engineering, committed to delivering long-lasting, efficient, and affordable nickel alloy solutions both within the UAE and across the world.
Nickel Alloy 201 Foils are composed of a minimum of 99.6% nickel, combined with small quantities of iron, manganese, copper, carbon, and silicon. This alloy is well known for its outstanding resistance to corrosion, especially in caustic and reducing conditions. It offers a tensile strength of roughly 370 MPa, a yield strength of 100 MPa, and remarkable ductility and thermal conductivity. Nickel Alloy 201 preserves its mechanical strength even at temperatures reaching 600°C, demonstrating superior toughness and magnetostrictive characteristics, which makes it ideal for high-temperature and electrically conductive applications requiring stability and reliability.
Specifications :ASTM B168 / ASME SB168
Size :1000 mm x 2010 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2010 mm x 2010 mm
Form :Foils, Rolls
Thickness :0.1mm to 12 mm Thk
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard and more.
Finish :Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated)
Other services :Heat treatment, Annealing, Pickling, Polishing, Electroplating, Anodizing, Rolling, Cutting, Forging, and so on.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest levels of quality and compliance.
Nickel Alloy 201 foils provide outstanding corrosion resistance, especially in alkaline settings, which makes them well-suited for chemical processing uses. They demonstrate superb thermal and electrical conductivity, high strength, and ductility, guaranteeing dependability across a range of conditions. The alloy retains excellent formability and weldability, permitting straightforward fabrication into thin, durable foils. Nickel Alloy 201 additionally withstands oxidation and is highly resistant to stress corrosion cracking, rendering it appropriate for uses in marine, aerospace, and electrical industries where durability and performance are essential.
Nickel Alloy 201 Foils find broad use across industries demanding first-rate corrosion resistance and thermal stability. They commonly appear in chemical processing, marine engineering, and power generation , where they serve to build heat exchangers, caustic evaporators, and reaction vessels . Within the electronics and aerospace fields , these foils prove indispensable for battery components, electrical connectors, and shielding materials thanks to their outstanding conductivity and low carbon content. They also see use in food processing, petrochemical, and laboratory equipment , delivering exceptional resistance to alkalis, acids, and high-temperature oxidation.
