Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, has earned a strong reputation for providing high-quality metal solutions engineered to perform in even the most demanding conditions. A featured item in their impressive range is the Inconel 718 Coil/Slitting Coil, renowned for its exceptional strength, corrosion resistance, and capacity to endure high temperatures. Produced using advanced metallurgical methods and stringent quality inspections, these coils are ideal for applications subjected to heavy stress and extreme heat. Al Shakru Sheets and Plates ensures that every Inconel 718 Coil/Slitting Coil meets international standards, guaranteeing dependability and longevity across numerous industries, including aerospace, marine, power generation, and chemical processing.
The Inconel 718 Coil/Slitting Coil is mainly composed of nickel (50–55%), chromium (17–21%), niobium (4.75–5.5%), and molybdenum (2.8–3.3%), together with small quantities of titanium, aluminum, and iron. It delivers a tensile strength of roughly 1240 MPa and a yield strength near 1035 MPa, giving it outstanding resistance to creep and fatigue. This alloy retains remarkable mechanical properties at temperatures as high as 700°C, while providing superb defense against oxidation and corrosion. Its finely balanced makeup guarantees excellent weldability, formability, and metallurgical stability, even in the harshest operating conditions.
Specifications :ASTM B670 / ASME SB670
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, and more
Length :2000mm, 2440mm, 3000mm, 5800mm, 6000mm, and more
Thickness :0.3 mm up to 120 mm
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard, and so on.
Finish :Hot rolled (HR), Cold rolled coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Coils, Shim Coils, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | Co |
| Inconel Alloy 718 | 0.08 max | 0.35 max | 0.35 max | 0.3 max | 0.015 max | 17 – 21 | 6.00 – 10.00 | 50 – 55 | 1.0 max |
| Density | Melting Point | Tensile Strength | Yield Strength 0.2% Proof | Elongation (% in 50mm) (thick.>0.76mm) |
| 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 135,000 , MPa – 930 | Psi – 70,000 , MPa – 482 | 45 % |
| Grade | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 718 | 2.4668 | N07718 | NCF 718 | – | – | – | – |
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing top-tier quality and compliance standards.
Inconel 718 Coil and Slitting Coil deliver remarkable resistance to high temperatures, making them well suited for demanding aerospace, chemical processing, and nuclear applications. They demonstrate excellent strength, exceptional fatigue and creep resistance, and outstanding corrosion resistance, especially in severe environments. These highly adaptable coils perform well in both elevated and cryogenic temperatures, guaranteeing lasting durability and reliability. Their superb mechanical properties and weldability make them a favored option for applications that demand high performance and longevity.
The Inconel 718 Coil/Slitting Coil is suited to a wide range of uses that demand high strength, resistance to heat, and protection against corrosion. It is frequently applied in aerospace engines, gas turbines, and jet propulsion systems, owing to its outstanding fatigue and creep resistance. Beyond that, it serves an essential function in power generation units, marine environments, and chemical processing plants. The alloy’s remarkable weldability and toughness make it a preferred option for producing springs, fasteners, heat exchangers, and high-pressure components. Its capacity to operate dependably under severe mechanical and thermal stress guarantees enduring safety and efficiency in vital industrial processes.
