Al Shakru Sheets and Plates is a premier manufacturer and supplier based in Dubai, UAE, specializing in high-quality Inconel 600 Channels designed for challenging industrial applications. Renowned for their precision, dependability, and advanced manufacturing expertise, the company produces materials that perform exceptionally in extreme conditions, including high temperatures, oxidation, and corrosive environments. Their Inconel 600 Channels are engineered to endure, delivering exceptional durability, structural integrity, and lasting performance, which makes them ideal for critical projects. Serving industries such as aerospace, chemical processing, power generation, and marine, Al Shakru Sheets and Plates offers tailored solutions that ensure reliable quality, operational efficiency, and superior mechanical performance in demanding industrial and high-temperature environments.
Inconel 600 Channels are composed primarily of nickel and chromium, with iron included to boost strength and corrosion resistance. This alloy delivers high tensile and yield strength, outstanding creep and rupture resistance, and solid ductility over a wide temperature range. Inconel 600 preserves its structural integrity even during thermal cycling and within corrosive settings, standing up to oxidation, pitting, and stress corrosion cracking. It further provides excellent weldability and formability, which makes it well suited for applications demanding durability, mechanical strength, and dependable long-term performance under harsh industrial conditions.
Specifications :ASTM B166 / ASME SB166
Angle Size Range :20 x 20 mm to 100 x 100 mm
Angles Thickness :3 to 12 mm (based on size)
Channel Size Range :Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness :5 to 6 mm (based on size)
Length :3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Lengths
| Grade | UNS | DIN | JIS | BS | GOST | AFNOR | EN |
| Alloy 600 | N06600 | 2.4816 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Alloy 600 | 0.15 max | 1.00 max | 0.50 max | 0.015 max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strengt | Yield Strength (0.2%Offset) | Elongation |
| Alloy 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
We supply materials accompanied by mill test certificates as well as third-party test certificates, guaranteeing top-tier quality and compliance standards.
Al Shakru Sheets and Platesbased in Dubai, UAE, is a top supplier and stockist of premium metal products, including sheets, plates, coils, foils, angles, channels, circles, and slitting coils, all delivered with outstanding service and customized to fulfill our customers specific requirements. With an emphasis on providing superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Known for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Inconel 600 Channelprovides many benefits, making it highly desirable in demanding industries. Its outstanding resistance to oxidation and corrosion guarantees durability in high-temperature and chemically harsh environments. The alloy retains strength and structural integrity under extreme thermal conditions, delivering excellent creep-rupture properties. Its adaptability enables it to perform effectively across a broad range of applications, including chemical processing, aerospace, and marine industries. Furthermore, Inconel 600 withstands stress-corrosion cracking and chloride-ion-induced pitting, ensuring long-term performance in tough environments, thereby lowering maintenance and replacement costs.
| Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) | Inconel Angle Bar Sizes (all Dimensions in milimeter) | Approx Weight Inconel Angle Bar (kilogram/meter) |
|---|---|---|---|
| 25 x 25 x 3 | 1.13 | 63 x 63 x 8 | 7.50 |
| 25 x 25 x 4 | 1.46 | 65 x 65 x 4 | 4.00 |
| 25 x 25 x 5 | 1.78 | 65 x 65x 5 | 5.02 |
| 30 x 30 x 3 | 1.37 | 65 x 65 x 8 | 7.75 |
| 30 x 30 x 4 | 1.78 | 70 x 70 x 5 | 5.35 |
| 30 x 30 x 5 | 2.20 | 70 x 70 x 6 | 6.40 |
| 40 x 40 x 3 | 1.83 | 75 x 75 x 6 | 6.85 |
| 40 x 40 x 4 | 2.41 | 75 x 75 x 8 | 9.05 |
| 40 x 40 x 5 | 2.97 | 80 x 80 x 6 | 7.35 |
| 50 x 50 x 4 | 3.05 | 80 x 80 x 8 | 9.65 |
| 50 x 50 x 5 | 3.78 | 80 x 80 x 10 | 11.98 |
| 63 x 63 x 4 | 3.90 | 100 x 100 x 8 | 12.20 |
| 63 x 63 x 5 | 3.90 | 100 x 100 x 12 | 18.00 |
| Size in Inches | Est. Weight per Ft. Lbs. | Est. Weight per 20′ Bar |
|---|---|---|
| 3/4 x 3/4 x 1/8 | 0.59 | 11.80 |
| 1 x 1 x 1/8 | 0.80 | 16.00 |
| 1 x 1 x 3/16 | 1.16 | 23.20 |
| 1 x 1 x 1/4 | 1.49 | 29.80 |
| 1-1/4 x 1-1/4 x 1/8 | 1.01 | 20.20 |
| 1-1/4 x 1-1/4 x 3/16 | 1.48 | 29.60 |
| 1-1/4 x 1-1/4 x 1/4 | 1.92 | 38.40 |
| 1-1/2 x 1-1/2 x 1/8 | 1.23 | 24.60 |
| 1-1/2 x 1-1/2 x 3/16 | 1.80 | 36.00 |
| 1-1/2 x 1-1/2 x 1/4 | 2.34 | 46.80 |
| 2 x 2 x 1/8 | 1.65 | 33.00 |
| 2 x 2 x 3/16 | 2.44 | 48.80 |
| 2 x 2 x 1/4 | 3.19 | 63.80 |
| 2 x 2 x 3/8 | 4.70 | 94.00 |
| 2-1/2 x 2-1/2 x 3/16 | 3.07 | 61.40 |
| 2-1/2 x 2-1/2 x 1/4 | 4.10 | 82.00 |
| 3 x 3 x 1/4 | 4.90 | 98.00 |
| 4 x 4 x 1/4 | 6.60 | 132.00 |
| 4 x 4 x 3/8 | 9.80 | 196.00 |
Yes,we provide custom dimensions for Inconel 600 Channel to suit particular project requirements. The team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
Inconel 600 Channels are widely employed across industries requiring outstanding resistance to heat and corrosion. Within aerospace, they serve in turbine components, exhaust systems, and heat shields. The chemical and petrochemical fields rely on them for reactors, piping systems, and heat exchangers. Power generation plants use Inconel 600 Channels in boiler components, furnace linings, and superheaters. Throughout the marine industry, they are deployed in seawater handling systems, offshore equipment, and structural frameworks. Their exceptional mechanical properties establish them as a preferred selection for these demanding conditions.
