Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, is proud to provide premium-quality Incoloy 800 Circles . These circles are renowned for their exceptional high-temperature strength, oxidation resistance, and resilience against corrosion. Built to excel in demanding industrial and chemical environments, they retain their performance and structural integrity even when subjected to extreme thermal and mechanical stresses. Al Shakru Sheets and Plates is dedicated to precision manufacturing, delivering uniform thickness and an excellent surface finish while adhering to international quality standards. Backed by a strong reputation for dependability and long service life, Incoloy 800 Circles from Al Shakru Sheets and Plates are ideal for critical components in chemical processing, power generation, and high-temperature industrial applications, ensuring durable performance and safety.
The Incoloy 800 Circle is a nickel-iron-chromium alloy composed of Nickel (30–35%) , Iron (39–45%) , and Chromium (19–23%) , together with minor quantities of Carbon, Titanium, and Aluminum . It offers remarkable mechanical characteristics, such as a tensile strength of 485–620 MPa , a yield strength of 205–275 MPa , and solid elongation, delivering superb ductility, toughness, and thermal stability under high-temperature and corrosive conditions.
Specifications : ASTM B409 / ASME SB409
Dimensions : ASTM, ASME, and API
Circle Diameter : 3″ DIA up to 38″ DIA 1500 lbs max
Rings Diameter : 3″ OD up to 48″ OD Up to 900 lbs max
Cutting : Plazma & Machined Cut
Forms : Forging & Plate Cut
| Grade | C | Mn | Si | S | Cr | Fe | Ni | Cu | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 19 – 23 | 39.50 min | 30 – 35 | 0.75 max | 0.15 – 0.60 | 0.15 – 0.60 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates based in Dubai, UAE, is a premier provider and stockholder of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all delivered with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying high-grade products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Incoloy 800 Circleprovides several important benefits, making it well-suited for high-temperature and corrosive settings. Its elevated nickel content delivers outstanding resistance to oxidation, carburization, and sulfur-bearing environments. The alloy’s chromium content improves its ability to withstand corrosion and scaling at high temperatures. Incoloy 800 also demonstrates exceptional mechanical characteristics, such as high tensile strength, creep resistance, and thermal stability, even at temperatures reaching 1100°F (600°C). These qualities make it perfect for applications in sectors like chemical processing, heat exchangers, and power generation, guaranteeing lasting performance and dependability.
Yes,we provide custom sizes for Incoloy 800 Circle to fit specific project needs. Our team at Al Shakru Sheets and Plates is committed to delivering tailored solutions for all your requirements. For more information, reach out to us at sales@alshakruplates.ae.
Incoloy 800 Circles are widely applied across industries that require materials capable of withstanding elevated temperatures and corrosion. Typical uses include furnace components, heat exchangers, boiler parts, chemical processing equipment, and nuclear power systems . They are also employed in petrochemical, aerospace, and industrial manufacturing , where structural parts must withstand oxidizing and reducing environments at high temperatures. The outstanding formability, weldability, and lasting durability of Incoloy 800 Circles from Al Shakru Sheets and Plates make them an ideal option for producing essential high-performance components in demanding industrial settings.
