Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, is pleased to provide top-grade Incoloy 800/800H/800HT Channels . These channels are renowned for their exceptional high-temperature strength, outstanding corrosion resistance, and lasting durability. Engineered to satisfy the demanding requirements of chemical, industrial, and power generation industries, they preserve their structural integrity and dependable performance even under extreme thermal and mechanical stress. Al Shakru Sheets and Plates is dedicated to precision manufacturing, guaranteeing uniform dimensions and an excellent surface finish while adhering to international quality standards. For long-term performance and reliability, Incoloy 800/800H/800HT Channels from Al Shakru Sheets and Plates are the preferred option for structural and high-temperature applications, delivering exceptional mechanical stability together with superior resistance to oxidation and corrosion.
Incoloy 800/800H/800HT Channels are produced from nickel-iron-chromium alloys, consisting of Nickel (30–35%) , Iron (39–45%) , and Chromium (19–23%) , together with minor quantities of Carbon, Titanium, and Aluminum . The 800H and 800HT grades are purpose-built to improve strength at high temperatures via precise regulation of carbon levels and heat treatment. They feature a tensile strength of 485–620 MPa , a yield strength of 205–275 MPa , and notable elongation, which results in outstanding ductility, toughness, and thermal stability in high-temperature and corrosive environments.
Specifications :ASTM B408 / ASME SB408
Angle Size Range :20 x 20 mm up to 100 x 100 mm
Angles Thickness :3 to 12 mm (varies with size)
Channel Size Range :Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness :5 to 6 mm (varies with size)
Length :3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on delivering exceptional products, we serve a broad range of industries, offering dependable solutions for varied applications. Our comprehensive inventory features Recognized for our distinctive finishing techniques and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Incoloy 800, 800H, and 800HTchannels provide multiple benefits, such as remarkable resistance to oxidation, carburization, and thermal breakdown under high temperatures. These alloys retain their strength and stability in harsh environments, making them well-suited for use in chemical processing, power plants, and heat exchangers. The Incoloy 800H and 800HT variants deliver improved creep strength and resistance to thermal fatigue, with 800HT providing better stability at elevated temperatures. Furthermore, these alloys demonstrate outstanding weldability, formability, and corrosion resistance, guaranteeing lasting reliability and durability in demanding industrial settings.
Yes,we provide custom dimensions for Incoloy 800 / 800H / 800HT Channel to satisfy particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For more information, reach out to us at sales@alshakruplates.ae.
Incoloy 800/800H/800HT Channels are used across a wide range of industries requiring outstanding high-temperature performance, resistance to corrosion, and mechanical dependability. Typical uses include furnace components, heat exchangers, boiler frames, chemical processing equipment, and nuclear power systems . They also serve in petrochemical, aerospace, and industrial manufacturing , where structural parts must withstand both oxidizing and reducing environments at high temperatures. With their superb formability, weldability, and lasting durability, Incoloy 800/800H/800HT Channels from Al Shakru Sheets and Plates are ideal for fabrication applications.
