Al Shakru Sheets and Plates is a dependable manufacturer and supplier of EN24 Sheets and Plates based in Dubai, UAE . We take pride in delivering premium alloy steel products renowned for their exceptional strength, toughness, and wear resistance. Our EN24 Sheets and Plates are produced with precision, employing advanced metallurgical methods and stringent quality control to ensure consistent thickness, a smooth surface finish, and reliable mechanical performance. These sheets and plates are ideal for heavy engineering, automotive, and industrial uses, offering superior fatigue resistance and dimensional stability even under high stress. Al Shakru Sheets and Plates serves a wide range of industries, including machinery, automotive, aerospace, and general engineering, supplying trustworthy and high-performance EN24 alloy steel solutions.
EN24 Sheets and Plates are produced from alloy steel containing chromium, nickel, and molybdenum , which endows them with outstanding hardness, tensile strength, and impact resistance . They feature tensile strength between 850 and 1000 MPa , a yield strength of 600 to 750 MPa , and remarkable ductility and toughness , making them well suited for demanding mechanical and structural applications.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | P | Mo | Mn | S | Cr | Si | Ni | |
| EN – 24 | .35 – .45 | .040 | .20 – .40 | .45 – .70 | .040 | .90 – 1.40 | .10 – .35 | 1.30 – 1.80 |
| Max Stress | 850-1000 n/mm2 | |
| Yield Stress | 680 n/mm2 Min | Up to 150mm LRS |
| 654 n/mm2 Min | 150 to 250mm LRS | |
| 0.2% Proof Stress | 665 n/mm2 Min | Up to 150mm LRS |
| 635 n/mm2 Min | 150 to 250mm LRS | |
| Elongation | 13% Min | (9% if cold drawn) |
| Impact KCV | 50 Joules Min | Up to 150mm LRS |
| 35 Joules Min | 150 to 250mm LRS | |
| Hardness | 248-302 HB |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad array of industries, offering dependable solutions for varied applications. Our large inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 817M40 | EN24 | 4340 | 1.6582 |
EN24 sheets and platesprovide numerous important advantages such as outstanding strength and toughness, making them well suited for high-pressure applications. They demonstrate superb fatigue and wear resistance, delivering durability in demanding environments. The elevated hardness and impact resistance of the alloy makes it appropriate for use in vital applications such as shafts, gears and machine parts. EN 24 also delivers superb mechanical properties and can be heat treated to attain desired mechanical properties. EN 24 is priceless in the aerospace, automotive and industrial industries for its reliability, versatility and performance under extreme conditions.
Yes,we provide custom sizes for EN24 Sheet and Plates to suit particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For more information, reach out to us at sales@alshakruplates.ae.
These EN24 Sheets and Plates are widely applied in gears, shafts, high-strength fasteners, axles, and components for heavy machinery thanks to their remarkable wear resistance and mechanical strength. Within industrial and fabrication settings , they serve in press tools, automotive parts, aerospace components, and general engineering structures that call for reliability, durability, and long-lasting performance. The combination of mechanical strength, toughness, and versatility establishes EN24 Sheets and Plates as a leading option for demanding industrial, automotive, and engineering requirements.
