Al Shakru Sheets and Plates is a first-rate manufacturer and supplier based in Dubai, UAE, focusing on premium-grade Aluminium 5052 Plates and Sheets . These items are recognized for their remarkable corrosion resistance, moderate strength, and lightweight properties. Engineered with precision to comply with international standards, these plates and sheets provide exceptional durability, accurate dimensions, and simple fabrication, making them ideal for numerous marine, industrial, and transportation applications. At Al Shakru Sheets and Plates, cutting-edge manufacturing methods and strict quality control guarantee that their Aluminium 5052 Plates and Sheets offer both mechanical dependability and adaptability. Serving industries that require high-performance materials, the company supplies products built for enduring operational efficiency and structural integrity.
Aluminium 5052 Plates and Sheets are made up primarily of aluminium, along with 2.2–2.8% magnesium, 0.25% chromium, and minor quantities of silicon, iron, and copper. This distinctive composition produces a tensile strength of 215–275 MPa and a yield strength of 130–200 MPa. They offer outstanding corrosion resistance, solid weldability, and strong fatigue strength. Being both lightweight and long-lasting, Aluminium 5052 Plates and Sheets are ideal for uses that demand strength as well as resistance to environmental factors.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
| 0.50 | 0.50 | 3.8/4.9 | 0.30/0.9 | 1.2/1.8 | 0.10 | 0.25 | 0.15 | Balance |
| Hardness, Brinell | Poisson’s Ratio | Melting Point | Electrical Resistivity | Modulus of Elasticity | Specific Heat |
| 47 | 0.33 | 607 – 649 °C | 4.99e-006 ohm-cm | 70.3 GPa | 0.88 J/g-°C |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Aluminium 5052 Sheets and Platesprovide remarkable benefits, such as superb corrosion resistance, particularly in marine and industrial settings. Their favorable strength-to-weight ratio makes them perfect for applications where durability and lightweight characteristics are crucial. They demonstrate excellent weldability, permitting straightforward fabrication and assembly. Aluminium 5052 preserves its structural integrity under harsh conditions and resists stress cracking. Furthermore, it offers good formability, allowing for intricate shapes and designs. These attributes make it a flexible and dependable material for marine, automotive, construction, and chemical processing applications.
Yes,we provide custom dimensions for Aluminium 5052 Plates and Sheets to satisfy particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg2,5 | AG2,5C | 3.3523 | A95052 | AlMg2,5 | 5052 | AlMg2,5 |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
These plates and sheets are widely employed in the marine industry for shipbuilding, decks, and hulls, owing to their outstanding resistance to saltwater corrosion. They are also used in the automotive and transportation sectors for chassis components, fuel tanks, and structural assemblies. In addition, these materials are perfect for chemical processing equipment, storage tanks, roofing, siding, and a range of industrial fabrication projects. Thanks to their durable performance, structural stability, and versatility, Aluminium 5052 Plates and Sheets are well-suited for demanding marine, industrial, and transportation applications.
