Browse Our Collection
Get instant quotes that fit your budget perfectly.
Al Shakru Sheets and Plates, based in Dubai, UAE, is a highly regarded manufacturer and supplier of premium Aluminium Channels. Known for their precision engineering and outstanding craftsmanship, Al Shakru Sheets and Plates delivers aluminium products customized to satisfy the diverse requirements of the construction, architectural, and industrial sectors. Aluminium Channels are prized for their excellent corrosion resistance, lightweight construction, and remarkable strength-to-weight ratio, making them ideal for both structural and decorative applications. With a firm dedication to quality assurance, innovation, and on-time delivery, Al Shakru Sheets and Plates ensures that every Aluminium Channel meets international standards of performance, reliability, and durability across a wide range of industries.
These Aluminium Channels are made mainly from aluminium, reinforced with regulated quantities of magnesium, silicon, manganese, and iron to improve strength, corrosion resistance, and machinability. They display a tensile strength between 150 and 310 MPa, a yield strength of 110 to 260 MPa, and an elongation of 8 to 12%, achieving an excellent balance between flexibility and toughness. These channels retain their mechanical integrity throughout fabrication operations such as cutting, welding, and bending, making them lightweight yet sturdy components well suited for both indoor and outdoor structural and architectural applications.
| Specifications | : | ASTM B308 / ASME B308 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Aluminium 6061 Angle | : | 5mm to 9mm |
| Aluminium 6061 Channel | : | 40mm*20mm~300mm*300mm |
| Aluminium 6061 Beam | : | 3″ thru 12.31″ |
| Aluminium 6061 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Si | Fe | Cu | Zn | Mn | Mg | Ti | Cr | Al | Others(Total) |
| Aluminium | 0.40 – 0.80 | 0.70 max | 0.15-0.40 | 0.25 max | 0.15 | 0.8-1.2 | 0.15 max | 0.04-0.35 | Balance | 0.15 max |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 45 | 310 | 21 | 145 | 25 | 65 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, such as Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Aluminium channelsprovide numerous important advantages, such as outstanding corrosion resistance, which makes them perfect for outdoor and marine uses. Because they are lightweight, they lower transportation and handling expenses, all while delivering remarkable strength and durability. Aluminium channels are extremely adaptable, simple to fabricate, and can be anodized to improve both look and protection. They further offer great thermal and electrical conductivity, which makes them appropriate for a wide range of engineering uses. On top of that, aluminium’s environmentally friendly characteristics, such as its recyclability, make it a sustainable option for industries aiming to lessen their environmental footprint.
Yes,we provide custom dimensions for Aluminium Channel to fit particular project requirements. Here at Al Shakru Sheets and Plates, our team is committed to delivering customized solutions for every one of your needs. To learn more, reach out to us at sales@alshakruplates.ae.
Al Shakru Sheets and Plates’ Aluminium Channels are widely used in construction, architectural frameworks, transportation, and industrial machinery thanks to their strength, durability, and resistance to corrosion. They work perfectly for support structures, framing systems, railings, window fittings, and equipment fabrication. Being lightweight and highly formable, they are well suited for projects that demand easy handling and lasting performance. Thanks to their outstanding mechanical properties and versatility, Aluminium Channels give engineers, fabricators, and designers a dependable and efficient material choice for a broad range of applications.
Our team stands ready to help you. Reach out to us with any questions or for tailored solutions.
