Al Shakru Sheets and Plates stands as a premier manufacturer and supplier based in Dubai, UAE, with expertise in high-quality Aluminium 2024 Plates and Sheets . These products earn recognition for their impressive strength, lightweight character, and superior fatigue resistance. Precision-engineered to satisfy international standards, these plates and sheets provide remarkable durability, accurate dimensions, and straightforward fabrication, which makes them ideal for challenging sectors such as aerospace, automotive, and industrial applications. At Al Shakru Sheets and Plates, cutting-edge production methods and stringent quality control guarantee that their Aluminium 2024 Plates and Sheets offer both mechanical reliability and versatility. Serving industries that require high-performance materials, the company supplies products that ensure structural integrity, enduring operational efficiency, and premium performance even under high-stress conditions.
Aluminium 2024 Plates and Sheets are primarily made of aluminium combined with 3.8–4.9% copper, 0.2–0.8% manganese, 0.2–0.5% magnesium, plus small quantities of silicon and iron. This distinctive composition produces a tensile strength in the 425–470 MPa range and a yield strength of 275–325 MPa. They offer outstanding fatigue resistance, solid machinability, and moderate corrosion resistance. On top of that, Aluminium 2024 Plates and Sheets can be heat-treated, which makes them perfect for uses that require a high strength-to-weight ratio and long-lasting performance.
| Standards | ASTM B209 / ASME SB209 |
| Temper | O,H12,H14,H16,H18,H19,H22,H24 |
| Thickness | 0.2-50 |
| Width | 100-2600 |
| Length | 500-10000 |
| Surface | Bright, polished, hair line, brush, sand blast, embossed, etching, etc. |
| Finish | Mill, Customer specific finish |
| Aluminum Sheet/ Plate Coating | PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating |
| Type | Hot-Rolled (HR) / Cold-Rolled (CR) Sheet |
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other |
| min. | Bal | 3.80 | 0.30 | 1.20 | ||||||
| max. | Bal | 0.50 | 0.50 | 4.90 | 0.90 | 1.80 | 0.10 | 0.25 | 0.15 | 0.05 |
| Temper | Tensile Strength | Yield Strength | Elongation |
| KSI | KSI | % | |
| (annealed) | 32 | 14 | 12 |
| T3 | 63 | 42 | 15 |
We supply products accompanied by mill test certificates as well as third-party test certificates, guaranteeing top-tier standards of quality and compliance.
Aluminium 2024 Sheets and Platesoffer numerous benefits, such as remarkable strength and strong fatigue resistance, which make them well-suited for aerospace, military, and structural uses. The elevated copper content improves its mechanical characteristics, delivering an outstanding strength-to-weight ratio, which is crucial in weight-conscious sectors like aviation. Aluminium 2024 also provides good machinability, enabling intricate designs and accurate fabrication. Although it has moderate corrosion resistance, it can be coated to boost its durability. Its strong performance, together with excellent wear resistance, makes it a favored option for challenging environments.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.1355 | A92024 | AlCu4Mg1 | 2024 | AlCuMg2 |
| Sizes (mm) | Theoretical Mass KG/Plate |
|---|---|
| 2000 X 1000 X 0.5 | 2500 X 1250 X 0.5 |
| 2000 X 1000 X 0.7 | 2500 X 1250 X 0.7 |
| 2000 X 1000 X 0.9 | 2500 X 1250 X 0.9 |
| 2000 X 1000 X 1.2 | 2500 X 1250 X 1.2 |
| 3000 X 1500 X 1.2 | 2000 X 1000 X 1.6 |
| 2500 X 1250 X 1.6 | 3000 X 1500 X 1.6 |
| 2000 X 1000 X 2.0 | 2500 X 1250 X 2.0 |
| 3000 X 1500 X 2.0 | 2500 X 1250 X 2.5 |
| 2.79 | 4.36 |
| 3.91 | 6.10 |
| 5.02 | 7.85 |
| 6.74 | 10.46 |
| 15.01 | 8.93 |
| 13.95 | 20.09 |
| 11.16 | 17.44 |
| 25.11 | 21.80 |
These plates and sheets are widely used in the aerospace and aviation sectors for aircraft structures, fuselage panels, and components subjected to high stress. They also have applications in the automotive field, functioning as chassis parts, machinery components, and structural elements that demand both strength and fatigue resistance. In addition, these plates and sheets are ideal for industrial fabrication, tooling, and equipment exposed to substantial mechanical loads. Thanks to their dependable performance, lasting durability, and structural stability, Aluminium 2024 Plates and Sheets are the preferred option for demanding industrial, aerospace, and automotive applications.
