Phosphorous Bronze Circle

Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, focuses on premium Phosphorous Bronze Circles that are renowned for their impressive strength, corrosion resistance, and exceptional wear performance. These circles are engineered to comply with international standards, combining the excellent mechanical qualities of bronze with the extra rigidity and longevity that phosphorus contributes. Al Shakru Sheets and Plates ensures accurate dimensions, a fine surface finish, and dependable quality, which makes these circles ideal for numerous industrial uses. The company caters to a wide range of sectors, such as marine, electrical, automotive, and mechanical engineering, delivering trustworthy Phosphorous Bronze Circles that provide durable performance, superior conductivity, and strength against fatigue and wear in demanding operational environments.

Phosphorous Bronze Circle

Phosphorous Aluminium Bronze

Phosphorous Industrial Circles

Phosphorous Bronze Circle Dealer in Abu Dhabi, Circle Phosphorous Bronze Supplier in Abu Dhabi, Phosphorous Bronze CR Circles Manufacturer in Al Ain, Phosphorous Bronze HR Circles Stockist, Phosphorous Bronze CR Circles Price List in Ajman, Phosphorous Bronze Hot Rolled Circles Supplier in UAE, Phosphorous Bronze Cold Rolled Circle in Jebel Ali, Phosphorous Bronze Hot Rolled Circle Supplier in UAE

Phosphorous Bronze Circles consist mainly of copper (roughly 90–95%), tin (about 4–10%), and phosphorus (around 0.01–0.35%), producing a distinctive combination of strength, hardness, and corrosion resistance. These circles offer remarkable tensile strength, generally ranging from 350–550 MPa, together with solid ductility and fatigue resistance. Their low friction coefficient, high wear resistance, and durability in both marine and industrial settings make them well-suited for mechanical and electrical uses where strength and dependability matter most.

Phosphorous Bronze Circle Specification

Material	Phosphor Bronze Circle
Grade	Alloy 510, Alloy 521, Alloy 519, Alloy 544
Standard	ASTM B103
Size	Thickness 0.1 mm to 50 mm; Width up to 500 mm; Length up to 2000 mm
Surface	Rolling surface, Chemical cleaned, Grinding

Chemical Properties of Phosphorous Bronze Circle

Alloy	UNS Designation	Tin	Phosphorus	Iron, max	Lead, max	Zinc, max	Copper
510	C51000	4.2-5.8	.030-.35	0.1	0.05	0.3	remainder

Mechanical Properties of Phosphorous Bronze Circle

ASTM Specification	Temper	Tensile Strength	Rockwell B Scale	Superficial (30-T Scale)
ASTM Specification	Temper	min-max psi	min-max	min-max
Annealed	Annealed	43-58	12-64	24-59
H02	1/2 Hard	58-73	60-85	53-73
H04	Hard Tempered	76-91	84-93	71-78
H06	Extra Hard	88-103	89-96	74-81
H08	Spring Temper	95-110	92-98	76-82
H10	Extra Spring	100-114	94-99	77-83

Phosphorous Bronze Circle Distributor in Ajman, Phosphorous Bronze CR Circle Supplier in UAE ,Phosphorous Bronze Circle Supplier in Dubai, Stockist of Phosphorous Bronze Circle in Jebel Ali, Phosphorous Bronze Circle Supplier in UAE, Phosphorous Bronze Circle Price List in Ajman, Phosphorous Bronze Supplier in Jebel Ali,Phosphorous Bronze Circle Exporter in Abu Dhabi, Phosphorous Bronze Circle Exporter in UAE,316L Phosphorous Bronze Cold Rolled Circle Exporter in Al Ain

If You Are Looking To Buy High Quality Piping Products ?

We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.

Largest Phosphorous Bronze Circle Manufacturer and Exporter in Dubai, UAE

Al Shakru Sheets and Platesbased in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all delivered with outstanding service and customized to fulfill our customers specific needs. With an emphasis on providing superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our extensive inventory includes Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.

Phosphorous Bronze Circles Distributor in UAE, Phosphorous Bronze Forged Circle Exporter in Dubai, Phosphorous Bronze CR Circles Exporter in Jebel Ali, Phosphorous Bronze Large Diameter Circle Manufacturer in Dubai, Phosphorous Bronze Plazma Cut Circle Price List in UAE, Phosphorous Bronze Big Size Circle Distributor in Al Ain, Phosphorous Bronze Circle Cut Machined Circle Exporter in Ajman

Phosphorous Bronze Circleprovide numerous advantages such as high strength, solid corrosion resistance and enhanced corrosion resistance. The inclusion of phosphorus lends the material a tougher and more durable finish, making it perfect for heavy applications. It also demonstrates outstanding electrical conductivity and mechanical efficiency. Phosphor copper resists fatigue and offers superb formability, making it well-suited for use in marine applications, electrical components and automotive parts In addition to being highly resistant to oxidation, it guarantees durability and durability longer under extreme conditions. These qualities make it a dependable option for a wide range of industrial applications.

Types of Phosphorous Bronze Circle

Phosphorous Bronze Circles in Abu Dhabi, Phosphorous Bronze HR Circle Stockist in Al Ain, Phosphorous Bronze Circles Supplier in Dubai, Phosphorous Bronze Industrial Circles Exporter in Jebel Ali, Phosphorous Bronze HR Circles Price List in UAE, 316L Stainless Steel Cut Machined Circle in Al Ain, Phosphorous Bronze CR Circles Supplier in Abu Dhabi, Phosphorous Bronze Circles Distributor in UAE, Phosphorous Bronze Circles Supplier in UAE

Are Custom Sizes Available for Phosphorous Bronze Circle?

Yes,we provide custom dimensions for Phosphorous Bronze Circle to fit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your requirements. For further information, reach out to us at sales@alshakruplates.ae.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Phosphorous Bronze Circle

Phosphorous Bronze Circles are widely applied across industries requiring toughness, resistance to corrosion, and strong mechanical performance. Typical applications include marine components, bushings, bearings, and gears . Within the electrical and electronics sector , they are preferred for connectors, springs, and terminals thanks to their outstanding conductivity and resistance to wear. Their exceptional fatigue strength and dimensional stability additionally make them an excellent option for automotive components, precision machinery, and industrial hardware . Phosphorous Bronze Circles provide enduring reliability, protection against corrosion and wear, and steady performance across a wide range of applications.
