Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, focuses on high-quality Nitronic Sheets and Plates engineered for remarkable strength, corrosion resistance, and durability. These austenitic stainless steel products are built to satisfy stringent international standards, guaranteeing superior mechanical performance even in the harshest industrial environments. Al Shakru Sheets and Plates prides itself on providing accurate thickness, a uniform surface finish, and reliable material properties, which makes their Nitronic Sheets and Plates ideal for essential engineering and structural applications. The company caters to numerous industries, such as aerospace, chemical processing, marine, and power generation, offering sturdy solutions capable of withstanding high stress, extreme temperatures, and corrosive conditions while delivering enduring performance and reliability.
Nitronic Sheets and Plates are composed primarily of iron, chromium (roughly 17–20%), nickel (about 8–12%), and nitrogen (near 0.18%), together with small quantities of manganese and silicon. These sheets and plates deliver notable tensile strength in the 620–850 MPa range, elevated yield strength, and outstanding ductility. They provide superb resistance to corrosion, particularly in oxidizing and chloride-heavy conditions, while retaining excellent toughness and dimensional stability at high temperatures. Their distinctive combination of strength, corrosion resistance, and wear resistance makes them well suited for a broad range of industrial and structural uses.
| Standard : | UNS S21906 | AMS 5656 | MIL-T-9821 | ASTM A276 | ASME SA276 UNS S21800 | Alloy 218 | ASME SA 193 | AMS 5848 | ASTM A 193 EN 1.3964 | ISO 15156-3 | NACE MR0175 | UNS S20910 | AMS 5764 | ASTM A193 | Werkstoff 1.3964 |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Nitronic 40 / 50 / 60 (UNS-S20910, S21800, S21900) |
| STANDARD | UNS | EN | ISO | NACE | AMS | ASTM | Werkstoff | other |
| Nitronic 40 | S21906 | – | – | – | 5656 | A276 | – | MIL-T-9821 |
| Nitronic 50 | S20910 | 1.3964 | 15156-3 | MR0175 | 5656 | A193 | 1.3964 | MIL-T-9821 |
| Nitronic 60 | S21800 | – | – | – | 5848 | A193 | 1.3964 | Alloy 218 |
| Weight% | C | P | Si | Ni | Fe | Mn | S | Cr | N | Mo | Cu |
| Nitronic 40 (21-6-9) | 0.04 max | 0.060 max | 1.00 max | 5.5-7.5 | Bal | 8-10 | 0.030 max | 19-21.5 | 0.15-0.40 | 0.75 max | 0.75 max |
| Alloy | Cross Section Size | Test Direction | Yield Strength 0.2% | Ultimate Tensile Strength | Elongation in 2″(%) | Reduction of Area % | Rockwell B Hardness | ||
| ksi | MPa | ksi | MPa | ||||||
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Longitudinal | 62 | 428 | 95 | 655 | 46 | 69 | |
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Transverse | 52 | 358 | 93 | 641 | 30 | 45 | |
| Nitronic 40 (21-6-9) | 4″ (102mm) sq | Longitudinal | 56 | 386 | 97 | 668 | 53 | 73 | |
| Nitronic 40 (21-6-9) | 1″ (25.4mm)sq | Longitudinal | 52 | 358 | 101 | 696 | 53 | 73 | 90 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Al Shakru Sheets and Plates, located in Dubai, UAE, is a top supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on delivering exceptional products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory features Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Nitronic sheets and platesoffer a wide range of benefits, including outstanding corrosion resistance, which makes them well-suited for demanding environments like the marine and chemical processing industries. They deliver superb strength, toughness, and wear resistance, even at high temperatures, boosting their durability in tough applications. Nitronic alloys also demonstrate remarkable resistance to galling, guaranteeing extended service life in mechanical and aerospace components. Their capacity to preserve structural integrity under both stress and corrosion makes them a dependable option for industries that demand high performance and long-lasting reliability, such as aerospace, automotive, and marine.
Yes,we provide custom dimensions for Nitronic Sheets and Plates to suit particular project requirements. The team at Al Shakru Sheets and Plates is committed to delivering customized solutions for every one of your needs. To learn more, reach out to us at sales@alshakruplates.ae.
Nitronic Sheets and Plates are widely applied in industries that require high strength, corrosion resistance, and durability. They are commonly used in chemical processing equipment, pressure vessels, and storage tanks . Within the marine and offshore sectors , they function as structural components, piping systems, and in shipbuilding applications . Thanks to their excellent mechanical properties and resistance to wear and corrosion, they are also well suited for aerospace, power generation, and heavy machinery .
