Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, focuses on producing high-quality Monel K500 Channels engineered to endure demanding conditions across both industrial and marine environments. These channels are built to satisfy strict international standards, guaranteeing accurate dimensions, a smooth surface finish, and reliable mechanical performance. Combining advanced manufacturing techniques with rigorous quality control, Al Shakru Sheets and Plates reliably supplies high-performance products. They serve a range of industries, such as chemical processing, marine, aerospace, and oil and gas, offering Monel K500 Channels ideally suited for structural support, fabrication, and any use requiring resistance to seawater, acids, alkalis, and oxidation.
Monel K500 Channels are made up primarily of nickel (roughly 63–70%) and copper (about 28–34%), along with minor additions of aluminum and titanium to improve age-hardening. They deliver impressive tensile strength in the range of 860–1100 MPa, yield strength from 345–690 MPa, and notable ductility. These channels are recognized for their exceptional corrosion resistance in seawater, acids, and alkalis, retaining their mechanical stability even under elevated temperatures while providing superb toughness and formability. This distinctive combination of strength, hardness, and durability makes Monel K500 Channels perfectly suited for demanding structural, industrial, and high-performance applications.
| Specifications | : | ASTM B865 / ASME B865 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Monel 400 Channel | : | 40mm*20mm~300mm*300mm |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | C Channel, U Channel, Channels |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
| Grade | C | Mn | Si | Cu | Fe | Ni | S |
| Monel K500 | 0.25 max | 1.50 max | 0.5 max | 27.0-33.0 | 0.5 – 2 | 63.0 min | 0.010 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 1,60,000 , MPa – 1100 | Psi – 1,15000 , MPa –790 | 20% |
UNS N05500 C Channeldelivers outstanding benefits, such as excellent corrosion resistance in aggressive marine and chemical settings. Boosted by its precipitation-hardening treatment, it delivers markedly greater tensile and yield strength than Monel 400. The alloy shows strong resistance to stress corrosion cracking, pitting, and crevice corrosion, guaranteeing dependability under demanding conditions. Its elevated thermal and electrical conductivity make it well-suited for high-performance applications. Moreover, Monel K500 maintains strength and toughness over a broad temperature span, making it perfect for aerospace, marine, and industrial applications that demand durability and extended service life.
Yes,we offer custom sizes for Monel K500 Channel to fit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all of your requirements. For further information, reach out to us at sales@alshakruplates.ae.
| STANDARD | WERKSTOFF NR. | UNS |
| Monel K500 | 2.4375 | N05500 |
Monel K500 Channels are widely applied across industries requiring strong corrosion resistance, mechanical durability, and thermal stability. Their typical applications include marine structures, pump shafts, valves, and fasteners . Within the chemical processing and oil & gas sectors , they function in reactors, piping systems, and heat exchangers . Because they resist seawater, acids, and alkalis so effectively, they are also well-suited for aerospace components, industrial machinery, and high-performance engineering applications . Monel K500 Channels ensure lasting durability and accurate dimensions, making them a dependable option for a range of demanding applications.
