Al Shakru Sheets and Plates, a trusted manufacturer and supplier based in Dubai, UAE, is proud to provide premium-quality Monel 400 Sheets and Plates that are renowned for their outstanding corrosion resistance, remarkable strength, and enduring durability. Manufactured with precision using state-of-the-art technology, these sheets and plates comply with international quality standards, making them ideal for demanding environments. Al Shakru Sheets and Plates ensures excellent dimensional accuracy, an exceptional surface finish, and dependable mechanical performance, which makes Monel 400 Sheets and Plates well-suited for a wide range of industrial applications, including marine, chemical processing, and oil & gas sectors where reliability and corrosion resistance are crucial.
Monel 400 Sheets and Plates consist mainly of roughly 67% nickel and 30% copper, with small quantities of iron, manganese, carbon, and silicon. They offer excellent mechanical characteristics, boasting a tensile strength of about 480 to 620 MPa and a yield strength ranging from 170 to 345 MPa, together with notable toughness and ductility. These plates maintain their strength and resistance to corrosion even in acidic and alkaline settings, providing exceptional performance in marine and chemical uses while efficiently managing high temperatures and pressures.
Specifications :ASTM B127 / ASME SB127, AMS 4544
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, and more
Length :2000mm, 2440mm, 3000mm, 5800mm, 4000mm, and so on
Thickness :0.3 mm up to 120 mm
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard and others.
Finish :Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Plate Surface finish | Gauge (in) | Width (max in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| BA Mexinox only | 18–28 | 48 |
| Polished plate (not brushed) | 11–24 | 60 |
| Temper rolled plate Mexinox only | 13–29 | 48 |
We deliver products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Monel 400 Sheets and Plates deliver several important benefits, such as outstanding corrosion resistance, especially in seawater, acids, and alkaline settings. They demonstrate remarkable strength and durability across both high and low temperatures, which makes them well-suited for challenging industrial uses. With solid weldability, formability and resistance to stress corrosion cracking. Monel 400 is adaptable for a range of industries, including marine, chemical, and aerospace. Its resistance to oxidation and wear guarantees lasting performance, cutting down on maintenance and replacement expenses. Overall Monel 400 offers reliability, longevity, and strong performance in tough environments.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Monel 400 Sheets and Plates are widely applied in sectors that demand strength, resistance to corrosion, and durability. Typical applications include marine engineering, heat exchangers, chemical processing equipment, and oil & gas piping systems . Because they withstand seawater and acids, they are ideally suited for pump shafts, valves, condensers, and distillation towers . Furthermore, Monel 400 Sheets and Plates serve in aerospace, power generation, and desalination plants , where they deliver dependable performance in demanding operating environments, offering an extended service life and structural integrity.
