Al Shakru Sheets and Plates, a leading manufacturer and supplier based in Dubai, UAE, is proud to provide high-quality Monel 400 Foils engineered to endure demanding conditions with exceptional corrosion resistance, mechanical strength, and durability. These nickel-copper alloy foils are produced to comply with rigorous international standards, guaranteeing accurate thickness, a consistent surface finish, and reliable performance. By combining advanced manufacturing techniques with comprehensive quality control, Al Shakru Sheets and Plates supplies products that reliably deliver top-tier performance. Serving a wide range of industries, such as chemical processing, marine, aerospace, and oil and gas, they offer Monel 400 Foils that are ideal for applications requiring resistance to aggressive chemicals, seawater, and oxidation, ensuring enduring reliability and structural integrity.
Monel 400 Foils are composed primarily of nickel (roughly 63–70%) and copper (approximately 28–34%), with small quantities of iron, manganese, and carbon as well. They deliver notable tensile strength in the 550–750 MPa range, yield strength from 200–450 MPa, and outstanding ductility. These foils perform exceptionally at withstanding corrosion caused by seawater, acids, and alkalis, retain their mechanical integrity even under high temperatures, and offer solid thermal and electrical conductivity. This distinctive combination of strength, flexibility, and durability makes Monel 400 Foils well suited for challenging industrial, marine, and high-performance uses.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel DIN 2.4360 Foilsprovide remarkable benefits, such as superb corrosion resistance in seawater, acidic, and alkaline conditions, which makes them perfect for marine and chemical uses. They feature high mechanical strength and durability, guaranteeing lasting performance under harsh conditions. Monel 400 foils stay stable over a broad temperature range, delivering dependable operation in high-temperature environments. Their outstanding resistance to stress corrosion cracking and pitting boosts their reliability in critical uses. Simple to fabricate and weld, these foils are adaptable for application across various industries, including aerospace, marine, chemical processing, and electrical systems.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Monel 400 Foils are widely applied across industries demanding superior corrosion resistance, mechanical strength, and thermal stability. They are commonly employed in marine components, chemical processing equipment, and fasteners . Within the aerospace and oil & gas sectors , they play a vital role in piping systems, valves, and structural components . Their remarkable resistance to seawater, acids, and alkalis further makes them an excellent option for industrial machinery, heat exchangers, and high-performance engineering applications . Monel 400 Foils ensure lasting durability, dimensional stability, and reliable mechanical performance.
