Al Shakru Sheets and Plates, a well-regarded manufacturer and supplier based in Dubai, UAE, is proud to provide premium-quality Haynes Sheet and Plate . These materials are known for their exceptional high-temperature strength, resistance to corrosion, and overall durability. Engineered to satisfy the demanding requirements of aerospace, chemical, and industrial applications, these sheets and plates are constructed to preserve their structural integrity and offer dependable performance even when subjected to extreme thermal and mechanical stresses. At Al Shakru Sheets and Plates, precision manufacturing takes center stage, guaranteeing uniform thickness and an excellent surface finish while adhering to international quality standards. The Haynes Sheet and Plate from Al Shakru Sheets and Plates is ideal for critical components in high-temperature and corrosive settings, delivering enduring reliability, exceptional performance, and structural stability for advanced engineering projects.
Haynes Sheet and Plate is a superalloy built on a nickel-chromium base, comprising Nickel, Chromium, Tungsten, Molybdenum , together with small quantities of Iron, Cobalt, and Carbon , varying according to the particular Haynes grade. Such materials offer outstanding mechanical characteristics under high-temperature conditions, delivering tensile strength between 850–1,200 MPa , yield strength of 400–700 MPa , and remarkable resistance to creep, oxidation, and corrosion. This alloy is recognized for its excellent ductility, toughness, and thermal stability, which makes it well-suited for the demanding operating conditions encountered in chemical and high-temperature industrial environments.
| Specification : | AMS 5608 / AMS 5609 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 188 (UNS R30188) |
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe | W | B | Mo | Co |
| Haynes 188 | .05 – .15 | 1.25 max | .020 max | .015 max | .20 – .50 | 20.0 – 24.0 | 21.0 -23.0 | 3.0 max | 13.0 -15.0 | .015 max | .03 – .15 | – |
| Yield Strength | Tensile Strength | Elongation | ||
|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % |
| 65 | 446 | 140 | 963 | 55 |
| STANDARD | Material No | UNS | Alloy |
| Haynes 188 | – | R30605 | 188 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Haynes sheets and platesare prized for their outstanding strength at high temperatures, resistance to oxidation and durability in demanding environments. Built from advanced nickel alloys that deliver excellent corrosion resistance, they are perfectly suited for tough conditions across space, chemical processing, and energy applications. Their capacity to retain high mechanical temperature, together with good weldability and formability, guarantees reliability and durability and is also recognized for ensuring excellent performance of mechanical products that demand more.
Haynes Sheet and Plate is widely employed across industries requiring outstanding high-temperature performance, resistance to corrosion, and mechanical dependability. Typical uses include gas turbine components, aerospace engine parts, combustion chambers, industrial furnaces, chemical processing equipment, and heat exchangers. They also serve in power generation, petrochemical, and high-temperature manufacturing systems, where preserving structural stability under extreme heat and oxidizing environments is essential. The exceptional formability, weldability, and durability of Haynes Sheet and Plate establish it as a preferred option for these challenging applications.
