Al Shakru Sheets and Plates, a premier manufacturer and supplier based in Dubai, UAE, is proud to provide high-grade Hastelloy C276 Sheet and Plates . These items are renowned for their exceptional corrosion resistance, remarkable strength, and enduring durability. Engineered to withstand the toughest chemical, marine, and industrial settings, these sheets and plates deliver dependable performance even under extreme conditions. Al Shakru Sheets and Plates is dedicated to precision manufacturing, providing exceptional surface finishes, and rigorously adhering to international quality standards. Relied upon by sectors such as chemical, aerospace, and power generation, Hastelloy C276 Sheet and Plates offer lasting reliability, structural integrity, and resistance to pitting, crevice corrosion, and oxidation, making them ideal for critical engineering and industrial applications.
Hastelloy C276 Sheet and Plates are manufactured using nickel-molybdenum-chromium alloys, comprising Nickel (57–63%) , Molybdenum (15–17%) , Chromium (14.5–16.5%) , and Iron (≤5%) , together with trace quantities of Cobalt and Tungsten . They demonstrate outstanding resistance to oxidizing and reducing agents alike, in addition to exceptional pitting and crevice corrosion resistance. Featuring a tensile strength of 485–690 MPa and a yield strength of 275–345 MPa , they further provide good elongation, delivering high toughness, ductility, and thermal stability for application in challenging chemical and high-temperature industrial environments.
| Type | Plate, Sheet, Strip, Coils, Foils, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate |
|---|---|
| Grade | Hastelloy C276 – ALLOY C-276 (Ni/ 15Cr/ 16Mo/ 4W)-UNS N10276 , ASTM B575 UNS N10276 |
| UNS N10276 Plate Length | 0-12mm or as required |
| Specification of Alloy C276 Plate | ASTM B575 UNS N10276, ASME SB575, MSRR, BS, AMS 4544 sheet |
| ASTM B575 Alloy C276 Plate Width | 0-2500mm or as required |
| Plate Thickness | 0.3 to 1200 mm or as required |
| C276 Hastelloy Plate Process | Hot/ Cold Rolled |
| Plate surface | No.1, No. 2D, No. 2B, BA, No.3, No.4, No.6, No.7, 2B, 2D, BA NO(8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled ASTM B575 Alloy C276 Plate, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Grade | C | Mn | And | S | Co | In | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000, MPa – 790 | Psi – 52,000, MPa – 355 | 40 % |
| Material | Ultimate Tensile (min) | Yield Strength (Min) | Elongation % | Hardness Rb | ||
|---|---|---|---|---|---|---|
| Ksi | Mpa | Ksi | Mpa | |||
| C276 Plate | 107.4 | 741 | 50.3 | 347 | 67 | 89 |
| C276 Sheet | 115.5 | 796 | 54.6 | 376 | 60 | 86 |
|
Stocked Sizes |
|
|---|---|
|
Size (in inches) |
Size (in mm) |
|
.125″ |
3.18mm |
|
.134″ |
3.40mm |
|
.156″ |
3.96mm |
|
.187″ |
4.75mm |
|
.250″ |
6.35mm |
|
.312″ |
7.92mm |
|
.375″ |
9.53mm |
|
.500″ |
12.7mm |
|
.600″ |
15.9mm |
|
.750″ |
19.1mm |
|
.875″ |
22.2mm |
|
1″ |
25.4mm |
|
1.125″ |
28.6mm |
|
1.250″ |
31.8mm |
|
1.500″ |
38.1mm |
|
1.750″ |
44.5mm |
|
2″ |
50.8mm |
|
2.500″ |
63.5mm |
|
3″ |
76.2mm |
We provide products supplied with both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Hastelloy C276 sheets and plates deliver remarkable benefits, making them well-suited for demanding industrial settings. They offer superior resistance against a broad spectrum of corrosive substances, such as powerful oxidizers, reducing agents, and chlorides, lowering the likelihood of pitting, crevice corrosion, and stress corrosion cracking. Their strength at elevated temperatures and excellent weldability guarantee dependability in vital applications, like chemical processing and marine systems. Furthermore, Hastelloy C276 maintains superior performance across both acidic and alkaline environments, delivering durability, prolonged service life, and lower maintenance, even in extreme conditions, boosting operational efficiency and safety.
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Hastelloy C276 Sheet and Plates are widely used across industries that demand outstanding corrosion resistance and dependable mechanical performance. Typical applications include chemical processing equipment, heat exchangers, reactor vessels, flue gas scrubbers, marine components, and pollution control systems . They also serve the aerospace, petrochemical, and pharmaceutical sectors , where structural parts must withstand highly corrosive chemicals and extreme temperatures. The outstanding formability, weldability, and durability of Hastelloy C276 Sheet and Plates from Al Shakru Sheets and Plates make them the perfect choice for these demanding applications.
