Al Shakru Sheets and Plates is a dependable manufacturer and supplier of Duplex Steel S32205 Sheets and Plates based in Dubai, UAE . We take great pride in delivering premium duplex stainless steel products that are recognized for their exceptional corrosion resistance, remarkable strength, and enduring durability. Our Duplex Steel S32205 Sheets and Plates are produced with precision, employing cutting-edge metallurgical methods and rigorous quality control procedures to ensure even thickness, a polished surface finish, and reliable performance. These sheets and plates are ideal for numerous applications across the chemical, marine, and industrial sectors, since they successfully withstand pitting, crevice corrosion, and stress corrosion cracking.
Al Shakru Sheets and Plates serves industries including oil and gas, chemical processing, marine engineering, and industrial manufacturing, supplying trustworthy duplex steel solutions.
Duplex Steel S32205 Sheets and Plates feature a well-proportioned austenitic (≈50%) and ferritic (≈50%) stainless steel microstructure , fortified with alloying elements such as chromium (≈22%), nickel (≈5–6%), molybdenum (≈3%), nitrogen, and trace elements . They deliver impressive tensile strength (≈650–800 MPa) , yield strength (≈450–550 MPa) , outstanding ductility , and superb resistance to pitting, crevice corrosion, and stress corrosion cracking , which makes them well suited for challenging industrial and marine settings.
| Specification | ASTM A 815, ASME SA 815, ASTM A 182, ASME SA 182 |
| Type | Seamless / Welded / Fabricated |
| Range | ½”NB to 24″NB in Sch 10S, 40S, 80S, 160s, XXS |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| S32205 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 116000 , MPa – 800 | Psi – 80000 , MPa – 550 | 15 % |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Duplex Steel Sheet and Plates S32205deliver a blend of high strength and outstanding corrosion resistance, which makes them well suited to harsh environments. Their balanced microstructure of austenite and ferrite improves resistance to stress corrosion cracking, pitting, and crevice corrosion. Thanks to superior mechanical properties, including high tensile strength and yield strength, S32205 is remarkably durable and dependable. These plates also deliver excellent weldability and formability, making them adaptable for a range of industrial applications such as chemical processing, offshore, and marine industries. They serve as a cost-effective substitute for pricier high-alloy steels under demanding conditions.
Yes,we provide custom sizes for Duplex Steel Sheet and Plates S32205 to fit particular project needs. Our team at Al Shakru Sheets and Plates is committed to delivering customized solutions for all your requirements. To learn more, reach out to us at sales@alshakruplates.ae.
| Duplex 2205 | UNS S31803 | 1.4462 | F51 |
| Thickness (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) | Length x width (mm) |
| 5 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 6 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 8 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 10 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 12 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 15 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 16 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 20 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 25 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 30 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 35 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 40 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 45 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 50 | 4000 x 2000 | 6000 x 2000 | 6000 x 2500 | 6000 x 3000 | 8000 x 2000 |
| 60 | 4000 x 2000 | ||||
| 70 | 4000 x 2000 | ||||
| 80 | 4000 x 2000 | ||||
| 90 | 4000 x 2000 | ||||
| 100 | 4000 x 2000 |
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
These Duplex Steel S32205 Sheets and Plates are widely employed in chemical processing equipment, heat exchangers, offshore structures, and marine constructions thanks to their exceptional corrosion resistance and favorable strength-to-weight ratio. Within industrial and fabrication settings , they serve in pressure vessels, piping, structural frameworks, and precision-engineered components where durability, reliability, and lasting performance are essential. In addition, these sheets and plates play a key role in oil and gas, desalination, and renewable energy projects , delivering operational efficiency, minimal maintenance requirements, and an extended service life. This distinctive blend of properties makes them a preferred option across a range of applications.
