Al Shakru Sheets and Plates is a first-rate manufacturer and supplier of Carbon Steel EN19 Sheets and Plates , proudly headquartered in Dubai, UAE . We focus on providing premium steel products that are designed for exceptional strength, toughness, and durability. Our EN19 Sheets and Plates are produced using advanced manufacturing methods and strict quality control processes, guaranteeing consistent dimensions, superb mechanical properties, and reliable performance even in the most demanding industrial and engineering environments. Well-known for their wear resistance and hardenability, these steel products are ideal for heavy-duty machinery, automotive components, and structural applications. Al Shakru Sheets and Plates serves a wide range of industries, including construction, manufacturing, automotive, and heavy engineering, offering solutions that not only comply with international standards but also satisfy long-term performance requirements.
Carbon Steel EN19 Sheets and Plates are mainly composed of carbon (0.36–0.44%) , manganese (0.60–0.90%) , chromium (0.90–1.20%) , and molybdenum (0.15–0.25%) , together with small quantities of phosphorus (≤0.035%) and sulfur (≤0.040%) . They offer remarkable tensile strength (700–900 MPa) , yield strength (500–600 MPa) , and outstanding hardness, wear resistance, and toughness . Thanks to these mechanical characteristics, EN19 Sheets and Plates are well suited for uses that require high load-bearing capacity, impact resistance, and precision machining.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 19 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
|
Max Stress |
Impact KCV |
Hardness |
Yield Stress |
0.2% Proof Stress |
Elongation |
|
850-1000 n/mm2 |
55 Joules Min |
248-302 HB |
.700 N/mm2 Min |
680 N/mm2 Min |
.9% Min |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
Carbon Steel EN19 Sheets and Platesoffer numerous benefits, such as superior tensile strength, which makes them well-suited for heavy-duty applications. Their outstanding fatigue and wear resistance guarantee durable performance in high-stress conditions. EN19 steel further delivers high toughness, lowering the chance of cracking or failure under load. Thanks to their good machinability and weldability, these plates can be readily fabricated into custom shapes and sizes for a range of applications. Moreover, their resistance to impact and shock loading makes them a favored option for automotive, engineering, and manufacturing applications.
Yes, we provide custom sizes for Carbon Steel EN19 Sheet and Plates to suit specific project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering tailored solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
Carbon Steel EN19 Sheets and Plates are widely used in automotive gears, shafts, crankshafts, machine components, and heavy-duty engineering applications because of their exceptional strength and resistance to wear. Within manufacturing and mechanical engineering , they serve in dies, industrial tools, and precision parts where durability and dependability are critical. Additionally, these sheets and plates play a vital role in construction equipment, industrial machinery, and metal fabrication , delivering ruggedness and enduring performance. The combination of mechanical strength, wear resistance, and hardenability they provide makes them a preferred option for tough applications.
