Al Shakru Sheets and Plates distinguishes itself as a premier manufacturer and supplier of C50 High Carbon Steel Sheets and Plates directly from Dubai, UAE . We take pride in delivering high-quality steel products engineered for outstanding strength, hardness, and durability. Our C50 Sheets and Plates are produced using advanced manufacturing methods and strict quality control, guaranteeing reliable performance even in the most demanding industrial and engineering settings. Ideal for heavy-duty fabrication, machining, and wear-resistant components, our products are relied upon across numerous industries. Al Shakru Sheets and Plates serves sectors such as automotive, machinery, tool-making, and construction, supplying steel solutions that not only comply with international standards but also ensure a long service life and reliable performance.
As for composition, C50 High Carbon Steel Sheets and Plates are primarily made up of carbon (0.47–0.55%) , manganese (0.60–0.90%) , and silicon (0.15–0.35%) , together with minor amounts of phosphorus (≤0.035%) and sulfur (≤0.040%) . These materials deliver remarkable tensile strength (700–800 MPa) , hardness (HRC 50–55) , and praiseworthy wear resistance and fatigue strength . These mechanical characteristics guarantee durability, toughness, and a high load-bearing capacity, which makes C50 Sheets and Plates well-suited for precision engineering and demanding industrial applications.
| Thickness Range | 0.10 – 5.00 MM |
| Width Range | 5.00 – 1250 MM |
| Form | Can be supplied in Coil or Sheet form |
| Sheet Length (CTL) | 300 – 3000 MM |
| Edge | Mill edge or Sheared edge |
| Coil / Sheet Pallet Weight | Weight of each Coil or Sheet pallet can be customized as per customer’s need |
| Coil ID / OD | ID or OD of each Coil can be customized as per customer’s need |
| Packing | High-end export packing for sea or road travel, completely safe during transit. Duly oiled with anti-rust oil, wrapped in hessian cloth & high-density plastic sheets to prevent moisture. Further strapped with high tensile strips. For identification & tracing, non-erasable polyester stickers are placed on each material |
| Delivery Time | Dispatched within 10 days to 2 months, depends upon the required size |
| Some Applications | Auto components such as Washers, Clutch components, various types of Springs, Pen Clips, Hanger Clips, Cycle/Motor Chains, etc. |
Element |
C |
Si |
Mn |
P |
S |
Cr |
Cu |
Ni |
Content (%) |
0.47 – 0.55 |
0.17 – 0.37 |
0.50 – 0.80 |
0.03 |
0.03 |
0.15 |
0.25 |
0.30 |
GRADE |
Tensile Strength min |
Yield Strength min |
Elongation min. |
contraction min |
impact min |
Hardness Max |
|
σb/M Pa |
σs/M Pa |
δ5/% |
ψ/% |
Akv/J |
Without heating |
annealing |
|
C50 |
630 |
375 |
14 |
40 |
31 |
241 |
207 |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
C50 High Carbon Steel Platesoffer many benefits, such as exceptional strength and hardness, which makes them well-suited for heavy-duty industrial uses. Their high tensile and yield strength deliver excellent load-bearing capacity, and their wear resistance ensures durability in tough environments. C50 plates also provide good machinability, enabling easy fabrication and customization for particular applications. The steel’s remarkable toughness and its capacity to endure high-stress conditions make it ideal for use in components such as gears, shafts, and machinery. What’s more, C50 High Carbon Steel Plates are cost-effective, delivering long-lasting performance and reliability.
Yes, we provide custom sizes for C50 High Carbon Steel Sheet and Plates to suit particular project requirements. Our team at Al Shakru Sheets and Plates is committed to delivering tailored solutions for all your needs. For further information, reach out to us at sales@alshakruplates.ae.
| SAE / AISI – American | SAE 1050 |
| DIN – Germany | C50 / CK50 |
| EN – English / BS – British | – |
| JIS – Japanese | S50C |
| UNI – Italy | C50 |
You’ll commonly see C50 High Carbon Steel Sheets and Plates put to use in automotive components, gears, shafts, cutting tools, and springs , applications where high strength and wear resistance are must-haves. Within the machinery and manufacturing sectors , they act as key building blocks for dies, industrial tools, and wear-resistant parts . On top of that, these plates play an essential role in construction equipment, heavy machinery, and metal fabrication , delivering the durability and reliability required under high stress. The combination of mechanical strength, toughness, and wear resistance makes C50 High Carbon Steel Sheets and Plates the preferred pick for demanding industrial and engineering applications.
