Al Shakru Sheets and Plates is a well-regarded manufacturer and supplier based in Dubai, UAE, focusing on high-quality Alloy C263 Foil engineered to endure elevated temperatures and demanding industrial environments. This alloy is renowned for its exceptional strength, oxidation resistance, and thermal stability, making it a dependable option in circumstances where conventional materials may fall short. At Al Shakru Sheets and Plates, they emphasize accurate manufacturing and rigorous quality control to guarantee compliance with international standards. They serve a range of industries, such as aerospace, power generation, and chemical processing, delivering long-wearing Alloy C263 Foil that provides enduring reliability and superior mechanical performance for essential engineering applications.
Alloy C263 Foil is a nickel-based superalloy, composed primarily of nickel, chromium, cobalt, and molybdenum, with the addition of aluminum and titanium to enhance its strength under high-temperature conditions. It demonstrates outstanding tensile and creep strength when subjected to elevated temperatures, together with remarkable resistance to oxidation and corrosion. Its typical tensile strength ranges from 950 to 1100 MPa, whereas the yield strength is approximately 550 to 650 MPa. Furthermore, Alloy C263 Foil retains solid ductility, thermal stability, and weldability, which makes it ideal for parts subjected to high thermal stress and mechanical loads in demanding industrial environments.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
We supply products accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest standards of quality and compliance.
| Properties | Metric | Imperial |
|---|---|---|
| Density | 8.359 g/cm3 | 0.302 lb/in3 |
| Melting point | 1300-1335°C | 2372-2471°F |
Alloy C263 foildelivers superb benefits for high temperature applications. It offers exceptional resistance to oxidation and creep, which makes it perfect for aerospace and industrial applications. The alloy’s high weldability and formability guarantee straightforward fabrication into complex shapes. Its outstanding thermal stability and resistance to cracking during thermal cycling improves reliability under extreme conditions. Furthermore, alloy C263 demonstrates corrosion and oxidation resistance up to 980°C (1800°F), delivering long-lasting durability. Its blend of strength, ductility and thermal performance makes it sought-after in gas turbines and heat treatment equipment.
You’ll find Alloy C263 Foil extensively adopted across industries that require outstanding high-temperature capability and mechanical strength. It’s frequently seen in gas turbines, jet engine components, heat exchangers, and furnace parts. Within the aerospace and power generation fields, it serves in turbine blades, combustion chambers, and structural components that function under severe thermal and mechanical conditions. The foil is likewise essential in chemical processing equipment, where resistance to oxidation and corrosion is critical. With Alloy C263 Foil , you can rely on extended service life, dependability, and structural integrity in demanding environments, making it a preferred material for high-performance applications.
