Al Shakru Sheets and Plates is a well-regarded manufacturer and supplier based in Dubai, UAE, with expertise in premium Alloy 20 Sheets and Plates engineered to provide outstanding corrosion resistance, durability, and performance in demanding industrial environments. Each sheet and plate is precision-crafted to comply with international standards, guaranteeing superior mechanical strength and enduring dependability. Through a dedication to strict quality control and cutting-edge manufacturing techniques, Al Shakru Sheets and Plates supplies Alloy 20 Sheets and Plates ideally suited for essential applications across chemical processing, pharmaceuticals, food production, and power generation. The company emphasizes strength, stability, and corrosion resistance, delivering products that meet the highest benchmarks for both industrial and structural purposes.
Alloy 20 Sheets and Plates are manufactured from nickel-chromium-iron based alloy steels, with copper and molybdenum incorporated to enhance their resistance to pitting, stress corrosion cracking, and oxidizing agents. Generally, their makeup consists of 32–38% nickel, 19–21% chromium, 2–3% molybdenum, and 3–4% copper. They deliver a tensile strength of roughly 620 MPa and a yield strength of about 300 MPa, together with outstanding ductility, formability, and weldability. Alloy 20 Sheets and Plates retain their mechanical integrity and corrosion resistance even under demanding chemical and thermal conditions.
Specifications :ASTM B463 / ASME SB463
Width :1000mm, 1219mm, 1500mm, 1800mm, 200mm, 2500mm, 3000mm, 3500mm, and more
Length :200mm, 2440mm, 3000mm, 5800mm, 200mm, and so on
Thickness :0.3 mm up to 120 mm
Hardness :Soft, Hard, Half Hard, Quarter Hard, Spring Hard and more.
Finish :Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange)
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
| Grade | C | Mn | Si | S | Cu | Ni | Cr | Fe | Mo | P |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 3.00 – 4.00 | 32.00 – 38.00 | 19.00 – 21.00 | 29.85 min* | 2.00 – 3.00 | 0.045 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
We supply materials accompanied by both mill test certificates and third-party test certificates, guaranteeing the highest levels of quality and compliance.
Al Shakru Sheets and Plates, headquartered in Dubai, UAE, is a top-tier supplier and stockist of premium metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all provided with outstanding service and customized to fulfill our customers specific needs. With an emphasis on supplying superior products, we serve a broad spectrum of industries, offering dependable solutions for varied applications. Our vast inventory includes Recognized for our distinctive finishing methods and dedication to quality. We are committed to guaranteeing customer satisfaction through reliable service and first-rate products.
Alloy 20 Sheets and Platesoffer remarkable benefits for challenging industrial settings. They deliver outstanding protection against corrosion, especially in sulfuric acid and chloride-heavy conditions, lowering maintenance expenses and prolonging equipment service life. Their impressive mechanical characteristics, such as high strength and durability, allow dependable operation under high-stress situations. Alloy 20’s resistance to pitting, crevice corrosion, and stress-corrosion cracking guarantees safety and efficiency in chemical processing, pharmaceuticals, and marine applications. Furthermore, they are adaptable and simple to fabricate, making them a favored option for tanks, piping, and heat exchangers.
Yes,we provide custom sizes for Alloy 20 Sheets and Plates to fit specific project needs. Our team at Al Shakru Sheets and Plates is committed to delivering tailored solutions for all your requirements. For further details, reach out to us at sales@alshakruplates.ae.
These sheets and plates find broad application across industries requiring strong corrosion resistance and mechanical stability. They are commonly seen in chemical processing equipment, storage tanks, piping systems, and heat exchangers exposed to sulfuric acid and other harsh chemicals. Within the pharmaceutical and food processing fields, these sheets and plates keep equipment safe and long-lasting. They are also put to use in power generation, desalination plants, and marine settings where withstanding corrosion and chemical attack is essential. Alloy 20 Sheets and Plates provide lasting dependability, structural soundness, and excellent performance.
